Produktbeskrivning
Easy-to-Use Managed Switches that Provide the Ideal Combination of Features and Affordability
To stay ahead in a competitive marketplace, small businesses need to make every dollar count. That means getting the most value from your technology investments, but it also means making sure that employees have fast, reliable access to the business tools and information they need. Every minute an employee waits for an unresponsive application - and every minute your network is down - has an impact on your bottom line. The importance of maintaining a strong and dependable business network only grows as your business adds more employees, applications, and network complexity.
When your business needs advanced security and features but value is still a top consideration, you're ready for the new generation of Cisco Small Business managed switches: the Cisco 300 Series.
Viktiga egenskaper
Cisco Small Business SG300-10MPP-K9-EU. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16384 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U
Teknisk specifikation
Management features
| Switch type | Managed |
|---|
| Switch layer | L3 |
|---|
| Quality of Service (QoS) support | Yes |
|---|
| Web-based management | Yes |
|---|
Ports & interfaces
| Basic switching RJ-45 Ethernet ports quantity | 8 |
|---|
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
|---|
| Gigabit Ethernet (copper) ports quantity | 8 |
|---|
| Combo SFP ports quantity | 2 |
|---|
| ExpressCard slot | No |
|---|
Network
| Networking standards | IEEE 802.1D,IEEE 802.1p,IEEE 802.1Q,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z |
|---|
| 10G support | No |
|---|
| Copper ethernet cabling technology | 1000BASE-T,100BASE-TX,10BASE-T |
|---|
| Port mirroring | Yes |
|---|
| Link aggregation | Yes |
|---|
| Rate limiting | Yes |
|---|
| Broadcast storm control | Yes |
|---|
| Head-of-line (HOL) blocking | Yes |
|---|
| Spanning tree protocol | Yes |
|---|
| Flow control support | Yes |
|---|
| VLAN support | Yes |
|---|
| Number of VLANs | 4096 |
|---|
Data transmission
| MAC address table | 16384 entries |
|---|
| Switching capacity | 20 Gbit/s |
|---|
| Forwarding rate | 14.88 Mpps |
|---|
| Number of queues | 4 |
|---|
| Jumbo frames support | Yes |
|---|
| Packet buffer memory | 1 MB |
|---|
Security
| DHCP features | DHCP client |
|---|
| Access Control List (ACL) | Yes |
|---|
| SSH/SSL support | Yes |
|---|
| MAC address filtering | Yes |
|---|
| Security algorithms | 802.1x RADIUS,HTTPS,SSH,SSL/TLS |
|---|
Multicast features
| Multicast support | Yes |
|---|
Protocols
| Management protocols | SNMP V1/V2c/V3, HTTP/HTTPS |
|---|
| Supported network protocols | IPv4, IPv6 |
|---|
Design
| Rack mounting | Yes |
|---|
| Form factor | 1U |
|---|
| Product colour | Black |
|---|
| LED indicators | Yes |
|---|
| Certification | UL (UL 60950), CSA (CSA 22.2), CE, FCC15 (CFR 47) A |
|---|
Performance
| Flash memory | 16 MB |
|---|
| Firmware upgradeable | Yes |
|---|
| Mean time between failures (MTBF) | 945042 h |
|---|
| Minimum system requirements | Mozilla Firefox v8, Microsoft Internet Explorer v7, Safari, Chrome |
|---|
Power
| Power supply included | Yes |
|---|
| Number of power supply units | 1 |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Input current | 2.5 A |
|---|
| Power consumption (typical) | 13.72 W |
|---|
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Yes |
|---|
| Power over Ethernet plus (PoE+) ports quantity | 8 |
|---|
| Total Power over Ethernet (PoE) budget | 124 W |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 45 °C |
|---|
| Storage temperature (T-T) | -20 - 70 °C |
|---|
| Operating relative humidity (H-H) | 10 - 90 % |
|---|
| Storage relative humidity (H-H) | 10 - 90 % |
|---|
| Heat dissipation | 493.05 BTU/h |
|---|
Weight & dimensions
| Width | 279.4 mm |
|---|
| Depth | 170 mm |
|---|
| Height | 44.45 mm |
|---|
| Weight | 1240 g |
|---|
Packaging data
| Cables included | Serial |
|---|
| Quick start guide | Yes |
|---|
Logistics data
| Harmonized System (HS) code | 85176990 |
|---|
