Allmänt
| Typ av enhet | Router - 4-ports-switch (inbyggd) |
|---|
| Modell | Skrivbordsmodell |
|---|
| Anslutningsteknik | Kabelansluten |
|---|
| Datalänkprotokoll | Ethernet, Fast Ethernet, Gigabit Ethernet |
|---|
| Nätverks/transportprotokoll | L2TP, RSVP, ICMP/IP, IPSec, FTP, DHCP, DNS, L2TPv3, DDNS, RTP, HTTP, HTTPs, cRTP |
|---|
| Nätverksprotokoll | OSPF, RIP-1, RIP-2, BGP, EIGRP, HSRP, VRRP, NHRP, IGMPv3, GRE, OSPFv3, PBR (policy-based routing), BGP-4+, WCCP, Bidirectional Forwarding Detection (BFD), RSVP, STP, MGRE |
|---|
| Protokoll för administration på distans | Telnet, SNMP 3, HTTP, HTTPS, SSH, CLI |
|---|
| Krypteringsalgoritm | DES, Tredubbel DES, AES, SSL, PKI, 128-bitars AES, 192-bitars AES, 256 bitars AES |
|---|
| Verifieringsmetod | Secure Shell (SSH), RADIUS, TACACS+ |
|---|
| Funktioner | NAT-stöd, auto-uplink (auto MDI/MDI-X), IGMP snooping, Stöd för DiffServ, MAC-adressfiltrering, Low-latency queuing (LLQ), Class-Based Weighted Fair Queuing (CBWFQ), Weighted Fair Queuing (WFQ), stöd för ACL (Access Control List), Quality of Service (QoS), Länkfragmentering och interleaving (LFI), Dynamic Multipoint VPN (DMVPN), DHCP-server, Virtual Route Forwarding-Lite (VRF-Lite), DNS proxy, DHCP-relä, DHCP-klient, Management Information Base (MIB), Neighbor Discovery Protocol (NDP), VPN-server, Flexible NetFlow (FNF), stöd för DiffServ Code Point (DSCP), Storm Control, SmartPort-teknologi, VPN-klient, Hierarchical Quality of Service (HQoS), Switched Port Analyzer (SPAN), Embedded Event Manager (EEM), Multigroup HSRP (MHSRP), Network-Based Application Recognition (NBAR), Network-Based Application Recognition (NBAR) 2, Performance Routing (PfR), Class-Based Traffic Shaping (CBTS), Class-Based Traffic Policing (CBTP), Class-Based Weighted Random Early Detection (CBWRED), Cisco IP Service-Level Agreement (IP SLA), Cisco Next Generation Plug-and-Play (NG PnP) Protocol |
|---|
| Standarder som följs | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1x, EN 61000-6-1, AS/NZS 60950-1, FCC CFR47 Part 15, UL 60950-1, IEC 60950-1, EN 60950-1, VCCI V-3, EN 61000-3-2:2006, EN 61000-3-3:2008, KN24, CNS13438:2006, EN 300 386 V1.6.1, CISPR 24:2010, EN 55024:2010, CISPR 22:2008, EN 300 386, TCVN 7189, EN 55032, CAN/CSA-C22.2 No. 60950-1, TCVN 7317, KN22:2009, ICES-003:2012 Issue 5 |
|---|
| Processor | 2.2 GHz |
|---|
| RAM | 1 GB |
|---|
| Flash-minne | 2 GB |
|---|
| Statusindikatorer | Status |
|---|
