Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon Silver 4310. Processor family: Intel Xeon Silver, Processor socket: LGA 4189, Processor lithography: 10 nm. Memory channels: Octa-channel, Maximum internal memory supported by processor: 6 TB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512, Scalability: 2S. Maximum Enclave Size Support for Intel® SGX: 8 GB. Processor package size: 77.5 x 56.5 mm



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor generation	3rd Generation Intel® Xeon® Scalable
Processor model	4310
Processor base frequency	2.1 GHz
Processor cores	12
Processor socket	LGA 4189
Processor lithography	10 nm
Cooler included	No
Component for	Server/workstation
Processor series	Intel Xeon Silver 4000 Series
Processor threads	24
System bus rate	10.4 GT/s
Processor operating modes	64-bit
Processor boost frequency	3.3 GHz
Processor cache	18 MB
Thermal Design Power (TDP)	120 W
Processor codename	Ice Lake
Processor ARK ID	215277

Maximum internal memory supported by processor	6144 GB
Memory types supported by processor	DDR4-SDRAM
Memory clock speeds supported by processor	2667 MHz
Memory channels	Octa-channel
ECC	Yes

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Market segment	Server
Maximum number of PCI Express lanes	64
PCI Express slots version	4.0
Supported instruction sets	SSE4.2,AVX,AVX 2.0,AVX-512
Embedded options available	Yes
Scalability	2S
Export Control Classification Number (ECCN)	5A992CN3
Commodity Classification Automated Tracking System (CCATS)	G178966

Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Speed Shift Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Crypto Acceleration	Yes
Maximum Enclave Size Support for Intel® SGX	8 GB
Intel Software Guard Extensions (Intel SGX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Optane™ DC Persistent Memory Supported	No
AVX-512 Fused Multiply-Add (FMA) units	2
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel 64	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Mode-based Execute Control (MBE)	Yes

Tcase	82 °C

Package type	Box

Supported memory types	DDR4-SDRAM
Target market	Cloud computing
Memory speed (max)	2667 MHz
Status	Launched
Number of UPI links	2
Launch date	Q2'21
Servicing status	Baseline Servicing

Harmonized System (HS) code	85423119

Processor package size	77.5 x 56.5 mm

Maximum internal memory	6000 GB
