Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon Silver 4509Y. Processor family: Intel® Xeon®, Processor socket: LGA 4677 (Socket E), Processor manufacturer: Intel. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2. Intel® Data Streaming Accelerator (DSA): 1 default devices. Processor package size: 77.5 x 56.5 mm



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel® Xeon®
Processor generation	Intel Xeon Scalable 5th Gen
Processor model	4509Y
Processor base frequency	2.6 GHz
Processor cores	8
Processor socket	LGA 4677 (Socket E)
Cooler included	No
Processor threads	16
Intel® UPI Speed	16 GT/s
Processor boost frequency	4.1 GHz
Processor cache	22.5 MB
Thermal Design Power (TDP)	125 W
Processor codename	Sapphire Rapids

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory channels	Octa-channel
ECC	Yes

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Market segment	Server
Use conditions	Server/Enterprise
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Scalability	2S
Embedded options available	Yes

Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Speed Shift Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Crypto Acceleration	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Mode-based Execute Control (MBE)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel® Boot Guard	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® OS Guard	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel 64	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® Data Streaming Accelerator (DSA)	1 default devices
Intel® Advanced Matrix Extensions (AMX)	Yes

DTS Max	100 °C
Tcase	84 °C

Package carrier	E1B
Launch date	Q4'23
Number of UPI links	2
Status	Launched

Processor package size	77.5 x 56.5 mm

Maximum internal memory	4000 GB
