Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon Gold 5520+. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4677 (Socket E), Processor manufacturer: Intel. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2. Maximum Enclave Size Support for Intel® SGX: 128 GB, Intel® QuickAssist Technology (QAT): 1 default devices, Intel® Dynamic Load Balancer (DLB): 1 default devices. Maximum internal memory: 4 TB



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel® Xeon® Gold
Processor generation	Intel Xeon Scalable 5th Gen
Processor model	5520+
Processor base frequency	2.2 GHz
Processor cores	28
Processor socket	LGA 4677 (Socket E)
Processor series	Intel Xeon Gold 5000 Series
Processor threads	56
Intel® UPI Speed	20 GT/s
Processor operating modes	64-bit
Processor boost frequency	4 GHz
High priority cores	8
High priority core frequency	2.4 GHz
Low priority cores	20
Low priority core frequency	2 GHz
Processor cache	52.5 MB
Thermal Design Power (TDP)	205 W
Stepping	R1
Processor codename	Emerald Rapids
Processor ARK ID	237561

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory channels	Octa-channel
ECC	Yes

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Market segment	Server
Use conditions	Server/Enterprise
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Scalability	2S
Embedded options available	Yes
Export Control Classification Number (ECCN)	5A992C
Commodity Classification Automated Tracking System (CCATS)	740.17B1

Intel Trusted Execution Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Maximum Enclave Size Support for Intel® SGX	128 GB
Intel® Platform Firmware Resilience Support	Yes
Intel® Crypto Acceleration	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel® Run Sure Technology	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel 64	Yes
Intel® Boot Guard	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® OS Guard	Yes
Intel® Volume Management Device (VMD)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® On Demand Feature Activation	Yes
Intel® QuickAssist Technology (QAT)	1 default devices
Intel® Dynamic Load Balancer (DLB)	1 default devices
Intel® Data Streaming Accelerator (DSA)	1 default devices
Intel® In-memory Analytics Accelerator (IAA)	1 default devices
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes
Intel® Speed Select Technology – Turbo Frequency	Yes

DTS Max	96 °C
Tcase	85 °C

Package carrier	E1B
Launch date	Q4'23
Status	Launched
Number of UPI links	3
Servicing status	Baseline Servicing

Harmonized System (HS) code	8542310001

Maximum internal memory	4000 GB
