Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon Gold 6526Y. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4677 (Socket E), Processor lithography: 7 nm. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Market segment: Server, Use conditions: Server/Enterprise, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel® Xeon® Gold
Processor generation	Intel Xeon Scalable 5th Gen
Processor model	6526Y
Processor base frequency	2.8 GHz
Processor cores	16
Processor socket	LGA 4677 (Socket E)
Processor lithography	7 nm
Processor series	Intel Xeon Gold 5000 Series
Processor threads	32
Intel® UPI Speed	20 GT/s
Processor operating modes	64-bit
High priority cores	4
High priority core frequency	3 GHz
Low priority cores	12
Low priority core frequency	2.6 GHz
Processor cache	37.5 MB
Thermal Design Power (TDP)	195 W

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	5200 MHz
Memory channels	Octa-channel
ECC	Yes
Non-ECC	No

Discrete graphics card	No
On-board graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Market segment	Server
Use conditions	Server/Enterprise
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Embedded options available	Yes
Scalability	2S

Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel Trusted Execution Technology	Yes
Intel® Speed Shift Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Trust Domain Extensions (Intel® TDX)	Yes
Intel® Crypto Acceleration	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel 64	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® OS Guard	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Run Sure Technology	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Boot Guard	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® Data Streaming Accelerator (DSA)	1
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes
Intel® Speed Select Technology – Turbo Frequency	Yes

DTS Max	99 °C
Tcase	82 °C

Package carrier	E1B
Number of UPI links	3
Launch date	Q4'23
Servicing status	Baseline Servicing
