Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon 6527P. Processor family: Intel Xeon 6, Processor socket: LGA 4710, Processor lithography: 3 nm. Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM, Memory clock speeds supported by processor: 6400 MHz. Market segment: Server, Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2, Scalability: 2S



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel Xeon 6
Processor model	6527P
Processor base frequency	3 GHz
Processor cores	24
Processor socket	LGA 4710
Processor lithography	3 nm
Processor threads	48
Intel® UPI Speed	24 GT/s
Processor operating modes	64-bit
High priority cores	8
Low priority cores	16
Low priority core frequency	0.8 GHz
Processor cache	144 MB
Thermal Design Power (TDP)	255 W

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	6400 MHz
ECC	Yes

Discrete graphics card	No
On-board graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Market segment	Server
Maximum number of PCI Express lanes	88
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Embedded options available	No
Scalability	2S

Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Speed Shift Technology	Yes
Intel Trusted Execution Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Crypto Acceleration	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Trust Domain Extensions (Intel® TDX)	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel® Run Sure Technology	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)	Yes
Intel® Secure Key	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
Intel 64	Yes
Intel® Boot Guard	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® QuickAssist Technology (QAT)	4
Intel® Dynamic Load Balancer (DLB)	4
Intel® Data Streaming Accelerator (DSA)	4
Intel® In-memory Analytics Accelerator (IAA)	4
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes
Intel® Speed Select Technology – Turbo Frequency	Yes

DTS Max	102 °C
Tcase	79 °C

Package carrier	E2B
Number of UPI links	4
