Produktbeskrivning

The Xeon® Processor from Cisco is designed to deliver enhanced reliability and flexibility for server platforms. This processor offers excellent performance and headroom for peak Internet server loads, resulting in faster response times, support for more users and improved scalability.



Viktiga egenskaper

Cisco Intel Xeon Gold 6544Y. Processor family: Intel® Xeon® Gold, Processor socket: LGA 4677 (Socket E), Processor manufacturer: Intel. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2, Scalability: 2S. Maximum Enclave Size Support for Intel® SGX: 512 GB



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel® Xeon® Gold
Processor generation	Intel Xeon Scalable 5th Gen
Processor model	6544Y
Processor base frequency	3.6 GHz
Processor cores	16
Processor socket	LGA 4677 (Socket E)
Processor series	Intel Xeon Gold 6000 Series
Processor threads	32
Intel® UPI Speed	20 GT/s
Processor operating modes	64-bit
Processor boost frequency	4.1 GHz
High priority cores	4
High priority core frequency	3.7 GHz
Low priority cores	12
Low priority core frequency	3.5 GHz
Processor cache	45 MB
Thermal Design Power (TDP)	270 W

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	5200 MHz
Memory channels	Octa-channel
ECC	Yes

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Maximum number of PCI Express lanes	80
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Scalability	2S

Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel Trusted Execution Technology	Yes
Intel® Speed Shift Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Maximum Enclave Size Support for Intel® SGX	512 GB
Intel® Crypto Acceleration	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Run Sure Technology	Yes
Intel® Volume Management Device (VMD)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	Yes
Intel® OS Guard	Yes
Intel 64	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Boot Guard	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® QuickAssist Software Acceleration	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® Data Streaming Accelerator (DSA)	1
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes
Intel® Speed Select Technology – Turbo Frequency	Yes

DTS Max	103 °C
Tcase	75 °C

Package carrier	E1B
Number of UPI links	3
