Produktbeskrivning

Intel Xeon 6787P Processor 336M Cache, 2.00 GHz



Viktiga egenskaper

Cisco Xeon 6787P. Processor family: Intel® Xeon®, Processor socket: LGA 4710, Processor manufacturer: Intel. Memory channels: Octa-channel, Maximum internal memory supported by processor: 4 TB, Memory types supported by processor: DDR5-SDRAM. Supported instruction sets: AMX, AVX, AVX 2.0, AVX-512, SSE4.2, Scalability: 2S



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel® Xeon®
Processor model	6787P
Processor base frequency	2 GHz
Processor cores	86
Processor socket	LGA 4710
Processor threads	172
Intel® UPI Speed	24 GT/s
Processor operating modes	64-bit
Processor boost frequency	3.8 GHz
All core Turbo frequency	3.2 GHz
High priority cores	36
High priority core frequency	2.1 GHz
Low priority cores	50
Low priority core frequency	1.6 GHz
Processor cache	336 MB
Processor cache type	L3
Thermal Design Power (TDP)	350 W
Number of QPI links	4
Processor codename	Granite Rapids

Maximum internal memory supported by processor	4000 GB
Memory types supported by processor	DDR5-SDRAM
Memory clock speeds supported by processor	6400 MHz
Memory channels	Octa-channel
ECC	Yes

On-board graphics card	No
Discrete graphics card	No
On-board graphics card model	Not available
Discrete graphics card model	Not available

Execute Disable Bit	Yes
Maximum number of PCI Express lanes	88
PCI Express slots version	5.0
Supported instruction sets	AMX,AVX,AVX 2.0,AVX-512,SSE4.2
Embedded options available	No
Scalability	2S

Intel Trusted Execution Technology	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Speed Shift Technology	Yes
Intel® Turbo Boost Technology	2.0
Intel® Transactional Synchronization Extensions	Yes
Intel® Total Memory Encryption	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Platform Firmware Resilience Support	Yes
Intel® Crypto Acceleration	Yes
Intel® Trust Domain Extensions (Intel® TDX)	Yes
Intel® Volume Management Device (VMD)	Yes
Mode-based Execute Control (MBE)	Yes
AVX-512 Fused Multiply-Add (FMA) units	2
Intel® Resource Director Technology (Intel® RDT)	Yes
Intel® Run Sure Technology	Yes
Intel 64	Yes
Intel® Secure Key	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® OS Guard	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® Speed Select technology - Performance Profile (Intel® SST-PP)	No
Intel® Boot Guard	Yes
Intel Software Guard Extensions (Intel SGX)	Yes
Intel® Speed Select Technology - Base Frequency (Intel® SST-BF)	No
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel QuickAssist Technology	Yes
Intel® QuickAssist Software Acceleration	Yes
Intel® Total Memory Encryption - Multi Key	Yes
Intel® QuickAssist Technology (QAT)	4
Intel® Dynamic Load Balancer (DLB)	4
Intel® Data Streaming Accelerator (DSA)	4
Intel® In-memory Analytics Accelerator (IAA)	4
Intel® Advanced Matrix Extensions (AMX)	Yes
Intel® Speed Select Technology – Core Power	Yes
Intel® Speed Select Technology – Turbo Frequency	Yes

DTS Max	97 °C
Tcase	80 °C
