Produktbeskrivning
Cisco 1000 Series Integrated Services RoutersThe Cisco® 1000 Series Integrated Services Routers (ISR 1000 Series) portfolio has been steadily expanding over the years to provide our customers with the flexibility they need. The ISR 1000 Series combines routing, switching, Wi-Fi, integrated security, and DSL and LTE uplink connectivity options in a single, lightweight, high-performance device. Choose between the traditional Cisco IOS® XE or controller-managed Cisco IOS XE SD-WAN software to deploy your network quickly and reliably on all Cisco ISR 1000 Series routers. With a simple and flexible pay-as-you-grow model, you purchase network capacity only when you need it.
Viktiga egenskaper
Cisco C1121-4P. Ethernet interface type: Gigabit Ethernet, Cabling technology: 10/100/1000Base-T(X), Ethernet LAN data rates: 10,100,1000 Mbit/s. Security algorithms: 802.1x RADIUS, IPSec, WPA2-AES, WPA2-RADIUS. Flash memory: 4000 MB, Internal memory: 4000 MB. Product colour: Silver. Power consumption (typical): 18.8 W, Power consumption (max): 66 W, Power source type: DC
Teknisk specifikation
WAN connection
| Ethernet WAN | Yes |
|---|
| DSL WAN | No |
|---|
| SIM card slot | No |
|---|
| 3G/4G USB modem compatibility | No |
|---|
Network
| Ethernet interface type | Gigabit Ethernet |
|---|
| Ethernet LAN | Yes |
|---|
| Cabling technology | 10/100/1000Base-T(X) |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
|---|
| Forwarding rate | 1372 Mpps |
|---|
| Number of users | 400 user(s) |
|---|
Management features
| Web-based management | Yes |
|---|
| Quality of Service (QoS) support | Yes |
|---|
Ports & interfaces
| Ethernet LAN (RJ-45) ports | 4 |
|---|
| USB ports quantity | 1 |
|---|
Security
| Security algorithms | 802.1x RADIUS,IPSec,WPA2-AES,WPA2-RADIUS |
|---|
| Firewall | Yes |
|---|
| Access Control List (ACL) | Yes |
|---|
| Network Address Translation (NAT) sessions (max) | 100 |
|---|
| VPN tunnels quantity | 100 |
|---|
Features
| Flash memory | 4000 MB |
|---|
| Internal memory | 4000 MB |
|---|
Design
| Product colour | Silver |
|---|
| LED indicators | Yes |
|---|
Power
| Power consumption (typical) | 18.8 W |
|---|
| Power consumption (max) | 66 W |
|---|
| Power source type | DC |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Output voltage | 12 V |
|---|
| Power over Ethernet (PoE) | Yes |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Storage temperature (T-T) | -40 - 70 °C |
|---|
| Operating relative humidity (H-H) | 10 - 85 % |
|---|
| Storage relative humidity (H-H) | 5 - 95 % |
|---|
| Operating altitude | 0 - 3048 m |
|---|
| Non-operating altitude | 0 - 4572 m |
|---|
Weight & dimensions
| Width | 322 mm |
|---|
| Depth | 226 mm |
|---|
| Height | 41.9 mm |
|---|
| Weight | 860 g |
|---|
Packaging data
| AC adapter included | Yes |
|---|
