Produktbeskrivning

Cisco® 1000 Series Integrated Services Routers (ISRs) with Cisco IOS® XE Software combine Internet access, comprehensive security, and wireless services (LTE Advanced 3.0 wireless WAN and 802.11ac wireless LAN) in a single, high-performance device. The routers are easy to deploy and manage, with separate data and control plane capabilities.

The Cisco 1000 Series ISRs are well suited for deployment as Customer Premises Equipment (CPE) in enterprise branch offices, in service provider managed environments as well as smaller form factor and M2M use cases.

Note: Not all 1000 series SKU variants are available in every region with different technologies (check on CCW pricelist for your region).



Viktiga egenskaper

Cisco C1121-8P. Networking standards: IEEE 802.11i, IEEE 802.11r, IEEE 802.1x, Ethernet interface type: Gigabit Ethernet, Cabling technology: 10/100/1000Base-T(X). USB version: 3.2 Gen 1 (3.1 Gen 1). Security algorithms: 3DES, AES, DES. Flash memory: 8192 MB, Internal memory: 8192 MB, Internal memory type: DRAM. Product colour: Silver



Teknisk specifikation

Ethernet WAN	Yes
DSL WAN	No
SIM card slot	No
3G/4G USB modem compatibility	Yes

Networking standards	IEEE 802.11i,IEEE 802.11r,IEEE 802.1x
Ethernet interface type	Gigabit Ethernet
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10,100,1000 Mbit/s

Internal modem	No

Web-based management	Yes
Quality of Service (QoS) support	Yes
Reset button	Yes

Ethernet LAN (RJ-45) ports	9
Gigabit Ethernet (copper) ports quantity	9
Power over Ethernet (PoE) ports quantity	4
Combo SFP ports quantity	1
USB ports quantity	2
USB version	3.2 Gen 1 (3.1 Gen 1)

Security algorithms	3DES,AES,DES
Firewall	Yes

Flash memory	8192 MB
Internal memory	8192 MB
Internal memory type	DRAM

Product colour	Silver

Power consumption (typical)	66 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Output voltage	12 V

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Operating relative humidity (H-H)	10 - 85 %
Storage relative humidity (H-H)	5 - 95 %
Operating altitude	0 - 3000 m

Width	322 mm
Depth	226 mm
Height	41.9 mm
Weight	1560 g

AC adapter included	Yes

Harmonized System (HS) code	85176990
