Produktbeskrivning

Provides power and connectivity

Allows delivery of both data and power for the Meraki MV smart camera over a single Ethernet cable allowing for simple installation.



Viktiga egenskaper

Cisco MA-INJ-6. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u. Product colour: Black, Maximum operating distance: 100 m, Power protection features: Short circuit. AC adapter input voltage: 100 - 240 V, AC adapter frequency: 50 / 60 Hz, Input current: 0.8 A. Certification: USA: FCC 15 B EU: EN55022 B cUL/US. Width: 160 mm, Depth: 52.5 mm, Height: 35.5 mm



Teknisk specifikation

Ethernet interface type	Gigabit Ethernet
Ethernet LAN data rates	10,100,1000 Mbit/s
Power over Ethernet (PoE)	Yes
Networking standards	IEEE 802.3,IEEE 802.3ab,IEEE 802.3at,IEEE 802.3u
Duplex system	Full

Product colour	Black
Wall mountable	Yes
Maximum operating distance	100 m
LED indicators	Yes
Power protection features	Short circuit
Certification	USA: FCC 15 B EU: EN55022 B cUL/US

Ethernet LAN (RJ-45) ports	2
RJ-45 input ports	1
RJ-45 output ports	1

AC adapter input voltage	100 - 240 V
AC adapter frequency	50 / 60 Hz
Input current	0.8 A

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C

Width	160 mm
Depth	52.5 mm
Height	35.5 mm
Weight	210 g

Harmonized System (HS) code	85044095
