Produktbeskrivning

Cisco Meraki MS210 switches provide Layer 2 access switching for branch and small campus locations. The MS210 includes 4 x 1G SFP uplinks and physically stacks with the MS225 to gain access to its 10G uplink. This family also supports an optional, rack-mountable PSU (Cisco RPS-2300) for power redundancy requirements
Cisco Meraki switches are built from the ground up to be easy to manage without compromising any of the power and flexibility traditionally found in enterprise-class switches.
The Meraki MS is managed through an elegant, intuitive cloud interface, rather than a cryptic command line. To bring up a Meraki switch, just plug it in; there’s no need for complicated configuration files or even direct physical access to the switch.
Meraki’s centralized management gives administrators deep visibility into the network and how it’s used. See which switches are near capacity across hundreds of sites. Find all configuration changes made by a certain person with instant search.

INDUSTRY LEADING CLOUD MANAGEMENT
Cloud management has a number of benefits that make it easier to build networks large and small:
- True zero-touch device provisioning.
- Virtual stacking: manage up to thousands of ports from a single pane of glass.
- Application layer visibility with automatic operating system, client, and hostname fingerprinting.
- Powerful Live Tools such as packet capture and cable test to isolate and troubleshoot network issues.
- Alerts upon power loss, downtime, or configuration changes.
- Role-based administration and automatic, scheduled firmware upgrades over the web.
- Regular feature updates and enhancements delivered on demand from the Meraki cloud.



Viktiga egenskaper

Cisco Meraki MS210-24P-HW. Switch type: Managed. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.11w, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1x, IEEE 802.3ad. Power over Ethernet (PoE). Rack mounting, Form factor: 1U



Teknisk specifikation

Switch type	Managed
Quality of Service (QoS) support	Yes
Web-based management	Yes
System event log	Yes

Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	0
SFP module slots quantity	4
Console port	RJ-45

Networking standards	IEEE 802.11w,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ab,IEEE 802.1p,IEEE 802.1x,IEEE 802.3ad
10G support	No
Port mirroring	Yes
Broadcast storm control	Yes
Link aggregation	Yes
Spanning tree protocol	Yes
VLAN support	Yes
Virtual LAN features	Voice VLAN
Number of VLANs	4094

MAC address table	16000 entries
Switching capacity	128 Gbit/s
Forwarding rate	41.67 Mpps
Static route	Yes
Jumbo frames support	Yes
Jumbo frames	9578

DHCP features	DHCP snooping,DHCP relay,DHCP client
Access Control List (ACL)	Yes
IGMP snooping	Yes
BPDU filtering/protection	Yes
Password protection	Yes
Authentication	MAC-based authentication
Security algorithms	SNMP
Authentication type	RADIUS

Multicast support	Yes

Switching protocols	LLDP, CDP, RSTP, STP

Rack mounting	Yes
Stackable	Yes
Form factor	1U
Product colour	Aluminium
Certification	CSA-US, FCC, IC, CE, RCM, RoHS

Physical stacking (units)	8
Firmware upgradeable	Yes
Mean time between failures (MTBF)	391648 h

Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
AC input frequency	47/63 Hz
Power consumption (typical)	448 W

Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	24
Power over Ethernet (PoE) power per port	30 W
Total Power over Ethernet (PoE) budget	370 W

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Width	484.6 mm
Depth	250 mm
Height	43.8 mm
Weight	3710 g

Screws included	Yes

Harmonized System (HS) code	85176990
