Produktbeskrivning
The UC-CX100-PRO-Z Crestron Flex integrator kit provides a customizable video conference solution for use with Zoom Rooms® software. It supports up to three video displays1 (not included), up to four cameras (not included), and features a UC presentation transmitter, a tabletop touch screen, and a UC bracket assembly.
Native Zoom Rooms® Software Experience
The UC-CX100-PRO-Z system features Zoom Rooms conferencing software that enables audio and video connectivity for easy collaboration and content sharing. It is compatible with Multi-camera, Multi-stream and Intelligent Director functions.
Custom Room Integration
The UC-CX100-PRO-Z system provides the essential components needed to design a fully custom video conferencing space using your choice of display devices, cameras, speakers, microphones, and other AV equipment. Any Zoom Rooms software certified USB camera such as the Crestron IV-CAMHK-12-SLVR-1B, IV-CAM-P12 and IV-CAM-P20 and a USB audio conferencing interface (or speakerphone) may be used.
Intuitive User Interface
With a large 10.1 in. (257 mm) capacitive touch screen display, the Crestron® tabletop touch screen (TS‑1070) provides superior conferencing control in meeting rooms, huddle spaces, and executive offices. The touch screen also offers optional control of room lighting, shades, thermostats, and other equipment.
Simplified Deployment
To simplify installation, the UC Bracket Assembly provides preassembled components on one ready-to-mount bracket. The assembly can be mounted on a wall, or it can be attached to the rear of the display device.
Bring Your Own Device (BYOD)
Conference room visitors can connect their laptop to the Crestron Flex system to use their own UC conference platform. The UC Presentation Transmitter (UC‑PR) switches to the connected laptop's UC platform and returns to the native platform when disconnected. For a list of BYOD tested devices on the UC‑PR, refer to OLH Article 1000889.
Enterprise‑Grade Security
Crestron Flex is an enterprise‑grade solution that is ideally equipped for mass deployment throughout any sized corporate, university, medical, military, or government facility.
Easy Provisioning and Device Management
The XiO Cloud® service is an IoT cloud-based provisioning service (available separately) that enables installers and IT managers to easily deploy and manage thousands of devices. The XiO Cloud service provides system alerts, network management and provisioning, and the pairing of a control device to the system’s UC Engine. System updates are controlled by Windows® software update.
Premium‑Level Support
Crestron Flex Care is an optional subscription service that can be renewed annually (up to 5 years from ship date). It provides 24/7 live remote technical support, an extended five-year warranty on Crestron® hardware, expedited advance replacements, and a discounted rate for on-site support.
Viktiga egenskaper
Crestron UC-CX100-PRO-Z. Product type: Personal video conferencing system, Number of persons: 1 person(s). Sensor type: CMOS. HD type: HD, Supported video modes: 1080p. Ethernet LAN, Wi-Fi. Display: LCD, Display diagonal: 25.6 cm (10.1"), Display resolution: 1920 x 1200 pixels. Product colour: Black
Teknisk specifikation
Performance
| Product type | Personal video conferencing system |
|---|
| Number of persons | 1 person(s) |
|---|
| Product colour | Black |
|---|
Video
| HD type | HD |
|---|
| Maximum video resolution | 1920 x 1200 pixels |
|---|
| Supported video modes | 1080p |
|---|
| Supported graphics resolutions | 1920 x 1200 (WUXGA) |
|---|
Ports & interfaces
| DisplayPort version | 1.2 |
|---|
Network
| Ethernet LAN | Yes |
|---|
| Ethernet LAN data rates | 100 Mbit/s |
|---|
| Wi-Fi | Yes |
|---|
| Networking standards | IEEE 802.1x,IEEE 802.3af,IEEE 802.3at |
|---|
| Cable standard | Cat5 |
|---|
| Security algorithms | SRTP,SSH,SSL/TLS |
|---|
Camera
| Megapixel (approx.) | 12 MP |
|---|
| Sensor type | CMOS |
|---|
| Image sensor size | 1/2.3 " |
|---|
Display
| Built-in display | Yes |
|---|
| Display | LCD |
|---|
| Display diagonal | 10.1 " |
|---|
| Display resolution | 1920 x 1200 pixels |
|---|
| Touchscreen | Yes |
|---|
| Touchscreen type | Capacitive |
|---|
Computer system
| Computer system type | Mini PC |
|---|
| VESA mounting | Yes |
|---|
| Windows operating systems supported | Windows 11 |
|---|
Power
| Power source type | AC |
|---|
| AC input voltage | 100 - 240 V |
|---|
| AC input frequency | 50 - 60 Hz |
|---|
| Current | 6 A |
|---|
| DC input voltage | 24 V |
|---|
| Power consumption (typical) | 60 W |
|---|
Weight & dimensions
| Width | 245 mm |
|---|
| Depth | 119 mm |
|---|
| Height | 134 mm |
|---|
| Weight | 1105 g |
|---|
Packaging content
| Cables included | DisplayPort to HDMI,HDMI,LAN (RJ-45),USB Type-A to Micro USB Type-B |
|---|
| Power cable length | 1.8 m |
|---|
| HDMI cable length | 1.8 m |
|---|
| AC adapter included | Yes |
|---|
| PoE adapter included | Yes |
|---|
| Mounting kit | Yes |
|---|
| Camera included | Yes |
|---|
| Manual | Yes |
|---|
| Quick start guide | Yes |
|---|
