Produktbeskrivning

KBR2D is the family of barcode scanners designed for self-service kiosks, ATMs, price checkers, healthcare and for any OEM application, also available in a plastic case version (KBR2D-C). KBR2D is a high-performance, high-volume omnidirectional scanner, capable of quickly and accurately reading any 1D and 2D barcodes, whether printed on paper (badges, receipts, health bracelets) or displayed on the screen of a smartphone or of a tablet. KBR2D scanners are based on CMOS technology for optimal image sensitivity and dynamic range. KBR2D integration is quick and easy thanks to several mounting options.



Viktiga egenskaper

CUSTOM KBR2D. Type: Barcode module bar barcode readers, Scanner type: 1D/2D, Linear (1D) barcodes supported: Codabar, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, GS1 DataBar Omnidirectional,.... Connectivity technology: Wired, Standard interfaces: RS-232, USB. Product colour: Black. Power source type: DC, Battery voltage: 5 V, Power consumption: 380 mA. Weight: 28 g, Width: 38.9 mm, Depth: 23.5 mm



Teknisk specifikation

Type	Barcode module bar barcode readers
Scanner type	1D/2D
2D (matrix & stacked) barcodes supported	Aztec Code,Data Matrix,Han Xin,Micro QR Code,MicroPDF417,PDF417,QR Code
Linear (1D) barcodes supported	Codabar,Code 128,Code 39,Code 93,EAN-13,GS1 DataBar Expanded,GS1 DataBar Omnidirectional,GS1 Databar Limited,Industrial 2 of 5,Interleaved 2 of 5,JAN,MSI,Matrix 2 of 5,Plessey,Telepen,UPC-A,UPC-E
Optical sensor resolution (W x H)	1280 x 800 pixels
Working distance	280 mm
Light levels (direct sunlight)	0 - 100000 lx
Pitch reading angle	5 - 60 °

Connectivity technology	Wired
Standard interfaces	RS-232,USB

Product colour	Black
LED indicators	Yes
Buzzer	Yes
Built-in display	No

Power source type	DC
Battery voltage	5 V
Power consumption	380 mA

Width	38.85 mm
Depth	23.5 mm
Height	5.2 mm
Weight	28 g

Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 95 %
