Produktbeskrivning

The TTP 8200 series kiosk printers offer 203-dpi resolution for full-format A4 or letter-size printouts of forms, bank statements, maps, or Web pages. The fast, compact, and low-maintenance design makes these printers ideal for unattended environments. The pull detector and jam-preventing loop presenter provide trouble free operation. The retract function keeps sensitive documents from being left behind outside the kiosk – and it saves media. If a printout is not taken from the printer, the output will be retracted and the remaining information can be deleted from the print queue, eliminating unwanted print jobs. The TTP 8200 is available in three configurations for flexible kiosk integration: standard, compact, and vertical, each equipped with standard USB and parallel interfaces. For additional configuration flexibility, the media can be mounted either behind or below the printer.



Viktiga egenskaper

Zebra TTP 8200. Print technology: Direct thermal, Maximum resolution: 203 x 203 DPI, Print speed: 100 mm/sec. Connectivity technology: Wired. Supported paper width: 216 mm



Teknisk specifikation

Print technology	Direct thermal
Colour	No
Maximum resolution	203 x 203 DPI
Print speed	100 mm/sec

Maximum roll diameter	250 mm
Supported paper width (imperial)	8.5 "
Media thickness (imperial)	0.002 - 0.004 "
Core diameter	25.4 mm
Supported paper width	216 mm
Media thickness	0.054 - 0.1 mm

Connectivity technology	Wired
Parallel ports quantity	1
USB 1.1 ports quantity	1

Built-in barcodes	Code 39
Certification	-UL, -cUL, -CE.

AC adapter output current	6 A
Power requirements	24 VDC

Operating relative humidity (H-H)	35 - 75 %
Storage relative humidity (H-H)	10 - 90 %
Storage temperature (T-T)	4 - 140 °F
Operating temperature (T-T)	5 - 50 °C
Storage temperature (T-T)	-20 - 60 °C

Weight	4800 g

Dimensions (WxDxH)	286 x 171 x 78 mm
