Produktbeskrivning

The smallest combined printer with high reliability features

TK180 is the smallest and highly reliable printer available. Optional paper roll holder. TK180 is equipped with a powerful internal processor and Hot swap function. Printing > 200 mm/s. The Ethernet, RS232 and USB interfaces assure easy and flexible integration. In addition to the most common sensors, it is also provided with the new mobile sensor, capable of identifying black marks or gaps on any type of paper. TK180 has an automatic sensor calibration feature which is automatically activated every time paper is loaded and prevents any ticket wastage thereby contributing to environmental sustainability and reducing management costs.



Viktiga egenskaper

CUSTOM TK180. Print technology: Thermal transfer, Maximum resolution: 203 x 203 DPI, Print speed: 200 mm/sec. Connectivity technology: Wired, Ethernet LAN, USB port. Supported paper width: 20 - 82.5 mm. Product colour: Black



Teknisk specifikation

Print technology	Thermal transfer
Colour	No
Maximum resolution	203 x 203 DPI
Print speed	200 mm/sec
Maximum printing width	80 mm
Vertical printing	Yes

Core diameter	25.4 mm
Supported paper width	20 - 82.5 mm
Media thickness	70 - 255 mm
Maximum roll diameter	200 mm

Connectivity technology	Wired
Ethernet LAN	Yes
Wi-Fi	No
USB port	Yes
USB 2.0 ports quantity	1
RS-232 ports	1

Internal memory	0.128 MB
Flash memory	1 MB
Built-in barcodes	AZTECCODE,CODABAR (NW-7),Code 128 (A/B/C),Code 39,Code 93,Data Matrix,EAN13,EAN8,PDF417,QR Code,UPC-A,UPC-E

Product colour	Black
Built-in display	Yes
Display	LCD

AC input voltage	110 V
AC adapter output voltage	24 V
AC adapter output current	1.5 A

Windows operating systems supported	Yes
Mobile operating systems supported	Android,iOS
Linux operating systems supported	Yes

Operating temperature (T-T)	-10 - 60 °C

Width	130 mm
Depth	185.9 mm
Height	118.9 mm
Weight	1900 g

Cables included	AC
