THE PURPOSE OF BAR CODE READERS IN THE HEALTHCARE INDUSTRY
The key mission of scanners in the healthcare industry is to improve the quality of patient care while reducing medication errors. Additionally, healthcare environments have requirements that
scanners need to be regularly cleaned and disinfected. The Datalogic Gryphon™ HC product series is specifically developed for healthcare applications with Disinfectant-Ready enclosures treated with antimicrobial additives and are designed to withstand daily cleaning with harsh disinfectant solutions.

The Gryphon 4500-HC 2D readers can decode virtually any 1D and 2D bar code symbology and can read codes from LCD monitors, cell phones, smartphones and other mobile devices. High Density (HD) models are also available for reading smaller, condensed codes.

Ideally suited for stationary applications in administration, laboratory and hospital environments, the GD4500-HC 2D desktop model offers an affordable corded solution, while the GM4500-HC 2D or GBT4500-HC 2D cordless models (STAR or Bluetooth®) provide extended mobility for cordless operations.

Datalogic’s distinctive reading technology with highly visible white or red-illumination is easier on the human eyes and reads colored labels better. The highly visible 4-Dot aimer provides a clear indication of the reading area, making targeting codes quick and easy. Datalogic’s patented ‘Green Spot’ technology provides additional visual good-read confirmation which is ideal for quiet environments such as bedside patient care.

The vibration option coupled with the silent operating mode can also be set to further increase the patients’ comfort. One of the most important technical innovations that the Gryphon 4500 wireless readers achieve is the wireless charging system for the battery, which enhances the reliability of the entire solution, while lowering the total cost of ownership (no need for contact cleaning or
maintenance procedures).



Viktiga egenskaper

Datalogic Gryphon GBT4500. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: Laser. Connectivity technology: Wireless, Standard interfaces: Bluetooth, Wireless range: 100 m. Product colour: Black, International Protection (IP) code: IP52, Protection features: Chemical resistant. Power source type: Battery, Battery technology: Lithium-Ion (Li-Ion), Battery capacity: 3250 mAh. Weight: 235 g, Width: 109 mm, Depth: 68 mm



Teknisk specifikation

Type	Handheld bar code reader
Scanner type	1D/2D
Sensor type	Laser
2D (matrix & stacked) barcodes supported	Data Matrix,GS1 DataBar Expanded Stacked,GS1 DataBar Stacked Omnidirectional,MaxiCode,Micro QR Code,MicroPDF417,QR Code
Optical sensor resolution (W x H)	1280 x 800 pixels
Light levels (direct sunlight)	0 - 100000 lx
Wavelength	650 nm
Tilt reading angle	0 - 360 °
Pitch reading angle	-65 - 65 °
Yaw reading angle	-65 - 65 °

Connectivity technology	Wireless
Standard interfaces	Bluetooth
Wireless range	100 m
Bluetooth version	4.0
Operating frequency	2400 MHz

Product colour	Black
International Protection (IP) code	IP52
Protection features	Chemical resistant
Image formats supported	BMP,JPEG,TIFF

Power source type	Battery
Battery technology	Lithium-Ion (Li-Ion)
Battery capacity	3250 mAh
Battery voltage	12 V
Number of reads per charge	80000
Charging time	4 h
Input voltage	4.5 - 14 V

Width	109 mm
Depth	68 mm
Height	166 mm
Weight	235 g

Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Operating temperature (T-T)	0 - 50 °C

Compliance certificates	RoHS

Harmonized System (HS) code	84716070
