Produktbeskrivning

The FlexScan EV2720S is a universal monitor with excellent image quality that impresses with its energy efficiency, ergonomics and reliability. With a diagonal of 27 inches and 2560 x 1440 pixels, it creates plenty of space for efficient working. The IPS panel with a detail resolution of 109 ppi and a contrast of 1500:1 ensures optimum readability, while the matte anti-glare coating and flicker-free brightness control with Auto EcoView ensure glare-free viewing. The monitor receives image, audio and USB data via the USB-C interface and offers 70 W charging power for fast and convenient notebook connection. Additional connection options are available thanks to DisplayPort and HDMI inputs as well as four USB downstream ports. The picture-in-picture mode allows different signal sources to be displayed simultaneously, ideal for connecting two computers. The virtually frameless design draws the eye to the essentials and supports clarity, especially in multi-monitor operation. A flexible stand allows the monitor to be rotated, swiveled and tilted for a comfortable sitting position. Controls, brightness sensor and speakers are integrated into the slim front panel. Thanks to its EcoView functions, the monitor impresses with its low power consumption. In short, the EV2720S is perfect for modern workstations in the office or at home.



Viktiga egenskaper

EIZO FlexScan EV2720S-BK. Display diagonal: 68.6 cm (27"), Display resolution: 2560 x 1440 pixels, HD type: Quad HD, Display technology: LCD, Response time: 5 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 1 (3.1 Gen 1). VESA mounting, Height adjustment. Product colour: Black



Teknisk specifikation

Display diagonal	27 "
Display resolution	2560 x 1440 pixels
Native aspect ratio	16:9
Display technology	LCD
Touchscreen	No
HD type	Quad HD
Panel type	IPS
LED backlight	Yes
Backlight type	W-LED
Display brightness (typical)	350 cd/m²
Response time	5 ms
Response time measurement type	GTG (Gray to Gray)
Anti-glare screen	Yes
Screen shape	Flat
Supported graphics resolutions	640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1600 x 1200 (UXGA),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080),1920 x 1200 (WUXGA),2560 x 1440
Contrast ratio (typical)	1500:1
Maximum refresh rate	60 Hz
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	16.7 million colours
Pixel pitch	0.233 x 0.233 mm
Pixel density	109 ppi
Horizontal scan range	31 - 89 kHz
Vertical scan range	59 - 61 Hz
Viewable size, horizontal	596.7 mm
Viewable size, vertical	335.7 mm
Display diagonal (metric)	68.5 cm
Colour gamut standard	sRGB

NVIDIA G-SYNC	No
AMD FreeSync	No
Flicker-free technology	Yes
Low Blue Light technology	Yes

Built-in speaker(s)	Yes
Built-in camera	No
Number of speakers	2
RMS rated power	2 W

Market positioning	Office
Product colour	Black
Feet colour	Black
Certification	CE, UKCA, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 10, TÜV/Low Blue Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC

Built-in USB hub	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-C
Number of upstream ports	1
Number of USB Type-C upstream ports quantity	1
USB Type-A downstream ports quantity	4
USB Type-C DisplayPort Alternate Mode	Yes
USB Power Delivery (USB PD)	Yes
USB Power Delivery up to	70 W
HDMI	Yes
HDMI ports quantity	1
DisplayPorts quantity	1
Headphone out	Yes
Headphone outputs	1
Headphone connectivity	3.5 mm
HDCP	Yes
HDCP version	1.4

VESA mounting	Yes
Panel mounting interface	100 x 100 mm
Cable lock slot	Yes
Height adjustment	Yes
Adjustable height (max)	169 mm
Pivot	Yes
Pivot angle	-90 - 90 °
Swivelling	Yes
Swivel angle range	0 - 344 °
Tilt adjustment	Yes
Tilt angle range	-5 - 35 °
On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	DEU,ENG,ESP,FRE,ITA

Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	15 kWh
Power consumption (typical)	14 W
Power consumption (standby)	0.4 W
Power consumption (max)	149 W
Power consumption (off)	0 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Energy efficiency scale	A to G

Operating temperature (T-T)	5 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80 %
Storage relative humidity (H-H)	10 - 90 %

Stand included	Yes
Cables included	USB Type-C to USB Type-C,AC
Quick start guide	Yes

Width (with stand)	611.6 mm
Depth (with stand)	230 mm
Height (with stand)	376.3 mm
Weight (with stand)	8500 g
Width (without stand)	611.6 mm
Depth (without stand)	59.7 mm
Height (without stand)	364.3 mm
Weight (without stand)	5700 g

Sustainability certificates	ENERGY STAR,EPEAT Climate +,EPEAT Gold,TCO
Sustainability compliance	Yes

Harmonized System (HS) code	85285210

Compliance certificates	CCC,CE,China RoHS,Federal Communications Commission (FCC),PSE,RoHS,TÜV mark,UKCA,VCCI,WEEE
Warranty period	5 year(s)

Picture-by-Picture (PbP)	Yes
Automatic brightness control	Yes
Look-up table (LUT) bit depth	10
