Produktbeskrivning

Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with and without stand options, you can easily configure the I‑Series to fit the needs of your business - from signage and point-of-sale to self-service, automation controls and more.

Universal VESA Mount
Conveniently mount the I‑Series with the built‑in VESA mount.

Expand with Edge Connect
Seamlessly attach a variety of peripherals to the edge of the touchscreen.

Reliable, security
and performance.
Built with the reliability-tested performance and security of Intel 12th Generation processors, integrated Trusted Platform Modules, Intel vPro™ and the Windows 10 operating system, the I‑Series 3 delivers the dependability businesses need.

Expand possibilities with AI processing.
Experience unparalleled AI processing power with the I-Series 3, featuring optional Hailo Neural Processing Engine capable of executing 50 TOPS (trillion operations per second). Available with i7 processor models.

Support for Linux.
For added flexibility, the I‑Series 3 offers no OS models, all pretested with Linux SuSE, Ubuntu and Red Hat operating systems.

Bridge the gap between Windows and Android.
Transitioning to Android in the future? Elo Bridge is the perfect solution. Simply choose the Elo Windows device that fits your needs today, and when you are ready to transition to Android, you can use Elo Bridge to migrate your fleet of devices.



Viktiga egenskaper

Elo Touch Solutions I‑Series 3. Display diagonal: 39.6 cm (15.6"), Display resolution: 1920 x 1080 pixels, HD type: Full HD. Product colour: Black, Mean time between failures (MTBF): 50000 h, Windows operating systems supported: Windows 10 IoT Enterprise, Windows 10 Pro, Windows 11 Enterprise, Windows 11 Pro. Processor manufacturer: Intel, Processor cache: 10 MB. Internal memory: 8 GB, Internal memory type: DDR5-SDRAM, Maximum internal memory: 32 GB. Optional connectivity: Bluetooth, Near Field Communication (NFC), Serial (RS-232)



Teknisk specifikation

Display diagonal	15.6 "
Display resolution	1920 x 1080 pixels
HD type	Full HD
Display type	LCD
Display brightness	350 cd/m²
Touchscreen	Yes
Effective viewing area	344.2 x 193.5 mm
Response time	25 ms
LED backlight	Yes
Native refresh rate	60 Hz
Number of colours	16.2 million colours
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Native aspect ratio	16:9
Viewing angle, vertical	170 °

Product colour	Black
Tilt adjustment	Yes
VESA mounting	Yes
Mean time between failures (MTBF)	50000 h
Windows operating systems supported	Windows 10 IoT Enterprise,Windows 10 Pro,Windows 11 Enterprise,Windows 11 Pro

Processor manufacturer	Intel
Processor cache	10 MB

USB 2.0 ports quantity	2
Optional connectivity	Bluetooth,Near Field Communication (NFC),Serial (RS-232)

Internal memory	8 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	32 GB
Memory clock speed	4800 MHz

Power source type	AC,DC
AC adapter frequency	50 - 60 Hz
Power	180 W
AC adapter input voltage	100 - 240 V
USB port voltage	5 V

Depth	44 mm
Width	384 mm
Height	237 mm
Weight	3600 g

Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	20 - 80 %
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 35 °C

Built-in speaker(s)	Yes
Number of speakers	2
