Produktbeskrivning
The Elo 2794L 27-inch open frame touchscreen display delivers an industrial-grade solution that is cost-effective for OEMs and systems integrators requiring a reliable product for their customers. Designed with reliability from the start, Elo's open frames deliver outstanding image clarity and light transmission with stable, drift-free operation for accurate touch responses. The 90-Series product line is available in a wide range of sizes, touch technologies and brightness, offering the versatility needed for commercial kiosk applications from self-service and gaming to industrial automation and healthcare.
Enabling Partners to Build Smarter Kiosks
With EloView® and the Backpack, managing kiosks is EASY! The Elo Backpack is an Android powered compute engine capable of transforming Elo touchscreens into an affordable, scalable, single-architecture media platform. With its simplified content-delivery and remote-management capabilities via the EloView portal, the Backpack provides a low-power, solid-state, fan-less computing solution with the capability to simplify deployments and remotely manage kiosks out-of-the-box.
Flexibility for Your Install
Our commercial-grade open frames can be mounted in landscape, portrait, and face-up orientations providing optimal flexibility for mounting in any table, kiosk, or cabinet design. Whether viewing directly, at an angle, or from a distance, our open frames offer what you need while maintaining optimal clarity and the viewing experience you want to deliver.
Touch Thru Glass Enabled with PCAP
Our TouchPro® PCAP technology supports touch thru functionality for installations that require a front layer of glass with thickness’s up to 6mm or solutions that require specific IP ratings. Whether you need a flush-mounted display or one that is fully-encased behind a cover glass, our robust PCAP Open Frames are purpose-built for durability in various applications and environments: from self-service kiosks to highly used gaming cabinets to harsh industrial machines.
Built for Commercial Use
We pride ourselves on being one of the best manufacturers in the market – We design and build the complete solution, with touch integrated from the start. Our robust touchscreen solutions offer flexibility for diverse environments and have undergone rigorous testing to ensure the longest life possible for our product - maximizing your ROI.
Viktiga egenskaper
Elo Touch Solutions 2794L. Display diagonal: 68.6 cm (27"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 300 cd/m², Touchscreen. Product colour: Black
Teknisk specifikation
Display
| Display diagonal | 27 " |
|---|
| Display technology | LED |
|---|
| Panel type | TFT |
|---|
| Display resolution | 1920 x 1080 pixels |
|---|
| Display brightness | 300 cd/m² |
|---|
| Touchscreen | Yes |
|---|
| Touchscreen technology | Projected capacitive system |
|---|
| Number of simultaneous touchpoints | 10 |
|---|
| Native aspect ratio | 16:9 |
|---|
| Response time | 12 ms |
|---|
| Contrast ratio (typical) | 3000:1 |
|---|
| Display number of colours | 16.78 million colours |
|---|
| Horizontal scan range | 30 - 82 kHz |
|---|
| Vertical scan range | 50 - 75 Hz |
|---|
| Supported graphics resolutions | 640 x 480 (VGA),720 x 400,800 x 600 (SVGA),1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 800 (WXGA),1366 x 768,1440 x 900 (WXGA+),1680 x 1050 (WSXGA+),1920 x 1080 (HD 1080) |
|---|
Ports & interfaces
| HDMI ports quantity | 1 |
|---|
| HDMI version | 1.3 |
|---|
| DisplayPorts quantity | 1 |
|---|
Design
| Product colour | Black |
|---|
| Screen shape | Flat |
|---|
| VESA mounting | Yes |
|---|
| Panel mounting interface | 200 x 100 mm |
|---|
Performance
| Mean time between failures (MTBF) | 50000 h |
|---|
Power
| Power consumption (typical) | 27 W |
|---|
| Power consumption (standby) | 1.5 W |
|---|
| Power consumption (off) | 0.5 W |
|---|
| AC input voltage | 230 V |
|---|
| AC input frequency | 50 Hz |
|---|
Packaging data
| Package width | 782 mm |
|---|
| Package depth | 200 mm |
|---|
| Package height | 530 mm |
|---|
| Package weight | 10200 g |
|---|
Packaging content
| Cables included | HDMI,USB,VGA |
|---|
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|
| Operating relative humidity (H-H) | 20 - 80 % |
|---|
| Storage temperature (T-T) | -20 - 60 °C |
|---|
| Storage relative humidity (H-H) | 10 - 95 % |
|---|
Certificates
| Certification | RCM; cUL, IC; CCC; CE TUV; VCCI; KCC; CoC; BSMI; UL, FCC; CB; WEEE |
|---|
Logistics data
| Harmonized System (HS) code | 85285210 |
|---|
Features
| Wall mountable | Yes |
|---|
Technical details
| Compliance certificates | RoHS |
|---|
Other features
| Display viewable area (HxV) | 597.89 x 336.31 mm |
|---|
| Height (without stand) | 41.8 mm |
|---|
| Built-in microphone | No |
|---|
| Depth (without stand) | 374.4 mm |
|---|
| Power supply type | AC |
|---|
| Weight (without stand) | 7300 g |
|---|
| Built-in camera | No |
|---|
