Produktbeskrivning

Modular design.
Endless versatility.
Available in sizes ranging from 15 to 24 inches, including with
and without stand options, you can easily configure the I‑Series
to fit the needs of your business - from signage and point-of-sale
to self-service, automation controls and more.

Reliable, security and performance.
Built with the reliability-tested performance and security of Intel 12th
Generation processors, integrated Trusted Platform Modules, Intel
vPro™ and the Windows 10 operating system, the I‑Series 3 delivers
the dependability businesses need.



Viktiga egenskaper

Elo Touch Solutions I-Series 3. Product type: All-in-One tablet PC. Display diagonal: 43.2 cm (17"), Display resolution: 1280 x 1024 pixels, Touchscreen, Screen shape: Flat, Panel type: TFT. Processor family: Intel® Core™ i7, Processor frequency: 1.8 GHz. Internal memory: 16 GB, Internal memory type: DDR5-SDRAM. Total storage capacity: 128 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics. Operating system installed: Windows 10. Product colour: Black



Teknisk specifikation

Display diagonal	17 "
Display resolution	1280 x 1024 pixels
Touchscreen	Yes
Native aspect ratio	5:4
Display brightness	250 cd/m²
Panel type	TFT
Response time	25 ms
Contrast ratio (typical)	1000:1
Screen shape	Flat
Viewing angle, horizontal	170 °
Viewing angle, vertical	160 °

Processor manufacturer	Intel
Processor family	Intel® Core™ i7
Processor generation	12th gen Intel® Core™ i7
Processor model	i7-1265UL
Processor threads	12
Processor frequency	1.8 GHz
Efficient cores	8
Performance-core Max Turbo Frequency	4.8 GHz
Efficient-core Max Turbo Frequency	2.7 GHz
Processor cache	12 MB
Processor cache type	Smart Cache
Processor base power	15 W

Internal memory	16 GB
Internal memory type	DDR5-SDRAM
Maximum internal memory	32 GB
Memory slots type	SO-DIMM
Memory clock speed	4800 MHz

Total storage capacity	128 GB
Storage media	SSD
Total SSDs capacity	128 GB
Number of SSDs installed	1
SSD capacity	128 GB
SSD interface	PCI Express 4.0
NVMe	Yes
SSD form factor	M.2

On-board graphics card	Yes
On-board graphics card family	Intel Iris Xe Graphics
On-board graphics card model	Intel Iris Xe Graphics

Built-in speaker(s)	Yes
Number of speakers	2
RMS rated power	4 W

Wi-Fi	Yes
Top Wi-Fi standard	Wi-Fi 6E (802.11ax)
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax)
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth version	5.0

Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
Headphone outputs	1

Product colour	Black
VESA mounting	Yes
Panel mounting interface	100 x 100 mm

Product type	All-in-One tablet PC
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Operating system installed	Windows 10
Operating system architecture	64-bit

AC adapter frequency	50 - 60 Hz
AC adapter input voltage	100 - 240 V
Power consumption (typical)	54 W

Width (with stand)	393.4 mm
Depth (with stand)	205.6 mm
Height (with stand)	371.2 mm
Package width	529 mm
Package depth	315 mm
Package height	539 mm

Operating temperature (T-T)	0 - 35 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	20 - 80 %
Storage relative humidity (H-H)	5 - 95 %

Mean time between failures (MTBF)	50000 h
