Produktbeskrivning

1504L 15-inch
Touchscreen Monitor
The 1504L touchmonitor delivers a stunning design, enhanced durability, increased touch accuracy and brilliant display clarity. With state-of-the-art optical bonding and IP54-sealed design, the 15” touch monitor offers a feature-rich platform and the versatility to extend across a diverse range of applications from point-of-sale, self-service and kitchen display systems to warehouse automation, access control and HMI.

Create the perfect payment stack with the 15" touchscreen.
Easily pair the 15-inch touchscreen monitor with one of Elo's integrated payment devices - from Elo Pay mobile computers to the Elo Pay 7", the 1504L offers the perfect compact touch display with the connectivity you need at the point of sale.

State of the art optical viewing.
Designed with high quality optical bonding, anti- glare coverglass and low-blue light settings - the 1504L 15-inch touch­screen monitor brings the best-in-class solution for viewing comfort and clarity.

Durable, energy efficient touchscreen.
- Scratch-resistant glass surface
- IP54 sealed design
- IK08 impact resistant
- Energy Star 8.0 certified

Secure your cables into place.
Never lose your port covers and screws with the security of the captive design. With a port cover that locks into place, cables are less prone to becoming disconnected, resulting in minimal disruptions to the device.

Connect accessories to the edge.
Elo Edge Connect™ offers an expansive lineup of accessories that seamlessly attach to the edge of the display including - EMVs, barcode scanners, status lights, cameras, RFID, MSR, fingerprint scanner and more.

Navigate the OSD directly on the touchscreen.
The on-screen display (OSD) controls are now directly on the touchscreen - making navigation easier while still offering OSD lock security.

Expand the possibilities with touch through.
Elo's TouchPro PCAP monitors feature touch through capability, supporting use with gloves and additional layers of films and filters to meet specific industry requirements.



Viktiga egenskaper

Elo Touch Solutions 1504L. Product design: Digital signage flat panel. Display diagonal: 39.6 cm (15.6"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 450 cd/m², Touchscreen. Product colour: Black



Teknisk specifikation

Display diagonal	15.6 "
Display technology	LED
Panel type	TFT-LCD
Display resolution	1920 x 1080 pixels
Display brightness	450 cd/m²
Touchscreen	Yes
Touchscreen technology	Projected capacitive system
Multi-touch	Yes
Number of simultaneous touchpoints	10
Response time	25 ms
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	178 °
Viewing angle, vertical	178 °
Display number of colours	16.7 million colours
Active display area (W x H)	344.16 x 193.59 mm
Display diagonal (metric)	419.1 cm
Number of displays	1
Native refresh rate	60 Hz
Horizontal scan range	30 - 82 kHz

HDMI ports quantity	1
DisplayPorts quantity	1
USB port	Yes
USB ports quantity	6
USB connector type	Micro-USB,USB Type-A,USB Type-C
Ethernet LAN	No
DC-in jack	Yes

Built-in speaker(s)	Yes
Number of built-in speakers	2
RMS rated power	4 W

Product design	Digital signage flat panel
Product colour	Black
Orientation	Horizontal/Vertical
Screen shape	Flat
VESA mounting	Yes
Panel mounting interface	75 x 75,100 x 100 mm
Anti-glare screen	Yes

On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN
Number of OSD languages	8
Mean time between failures (MTBF)	50000 h

Power consumption (typical)	12.1 W
Power consumption (sleep)	1 W
Power consumption (off)	0.25 W
Energy efficiency class (SDR)	E
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G

Display width	371 mm
Display depth	26.9 mm
Display height	227.5 mm
Display weight	1700 g
Weight (with stand)	2900 g

Package width	451 mm
Package depth	220 mm
Package height	342 mm
Package weight	5600 g

Stand included	Yes
Stand colour	Black
Cables included	HDMI,Power,USB Type-A to USB Type-C

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 95 %

Quantity per pack	1 pc(s)

Aspect ratio	16:9
