Produktbeskrivning

Razor thin design.
Brilliant touchscreen.
Built to be one of the thinnest commercial-grade 15-inch
touchscreen monitors, the 04LS-Series delivers a stunning
design with thin borders, enhanced durability and state-of-the-
art optical bonding - all with brilliant display clarity.

Available in a range of
sizes from 7- to 15-inch.

Secure your cables into place.
With a port cover that can be locked into place, cables are less prone
to becoming disconnected, minimizing disruptions to the device.

A clean slate for
touch experiences.

The perfect pairing for
your POS terminal.
Whether you want to pair the 1504LS with a PC, a mobile device
or an AiO with integrated payment, the 04LS slate monitors
offers the perfect compact touch display with the sleekness you
desire at the point of sale.

Get peace of mind
with EloCare
From advance unit replacement to extended warranties,
EloCare delivers service and support from the people
who know your Elo products best.



Viktiga egenskaper

Elo Touch Solutions 1504LS. Product design: Digital signage flat panel. Display diagonal: 39.6 cm (15.6"), Display technology: LED, Display resolution: 1920 x 1080 pixels, Display brightness: 350 cd/m², HD type: Full HD, Touchscreen. Product colour: Black



Teknisk specifikation

Display diagonal	15.6 "
Display technology	LED
Panel type	TFT-LCD
Display resolution	1920 x 1080 pixels
Display brightness	350 cd/m²
HD type	Full HD
Touchscreen	Yes
Touchscreen technology	Projected capacitive system
Multi-touch	Yes
Number of simultaneous touchpoints	10
Response time	20 ms
Contrast ratio (typical)	1000:1
Viewing angle, horizontal	170 °
Viewing angle, vertical	170 °
Display number of colours	16.2 million colours
Active display area (W x H)	344.16 x 193.59 mm
Number of displays	1
Native refresh rate	60 Hz

HDMI ports quantity	1
DisplayPorts quantity	1
USB port	Yes
USB ports quantity	1
USB connector type	USB Type-C
Ethernet LAN	No

Built-in speaker(s)	Yes
Number of built-in speakers	2
RMS rated power	4 W

Product design	Digital signage flat panel
Product colour	Black
Orientation	Horizontal/Vertical
Screen shape	Flat
VESA mounting	Yes
Panel mounting interface	75 x 75 mm
Anti-glare screen	Yes

On Screen Display (OSD)	Yes
On Screen Display (OSD) languages	CHI (SIMPL),CHI (TR),DEU,ENG,ESP,FRE,ITA,JPN
Number of OSD languages	8
Mean time between failures (MTBF)	50000 h

Power consumption (typical)	8 W
Power consumption (sleep)	0.8 W
Power consumption (off)	0.15 W
Energy efficiency class (SDR)	D
Energy consumption (SDR) per 1000 hours	8 kWh
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G

Display width	359.73 mm
Display depth	14.97 mm
Display height	218.82 mm
Display weight	1110 g

Package width	432 mm
Package depth	93 mm
Package height	295 mm
Package weight	1910 g

Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	10 - 95 %

Quantity per pack	1 pc(s)

Aspect ratio	16:9
