Take the Guesswork Out of Selecting Transceivers
Common connectivity problems in enterprise and data center networks are often traced back to low-quality and incompatible transceiver modules, rather than a fault in the network appliances themselves. Fortinet’s transceivers have been purpose-built and tested to work with Fortinet equipment, ensuring that your network is as stable and robust as possible, and taking the guesswork out of selecting compatible transceivers.

Wide Range for Maximum Flexibility
Supporting various form factors, media types, and throughput, Fortinet transceivers provide connectivity options to meet many different network architectures and deployment scenarios. Whether your network demands high-speed 100 GE inside the data center, or long-range 1 GE to connect data centers in different cities, Fortinet has a transceiver to meet your needs.



Viktiga egenskaper

Fortinet 100GE QSFP28 transceivers, 4 channel parallel fiber, short range for all systems with QSFP28 Slots. Maximum data transfer rate: 103100 Mbit/s, Interface type: QSFP28, Fiber optic connector: MPO12



Teknisk specifikation

Maximum data transfer rate	103100 Mbit/s
Interface type	QSFP28
Fiber optic connector	MPO12
Maximum transfer distance	100 m
Wavelength	850 nm
Networking standards	IEEE 802.3bm
Fiber ethernet cabling technology	100GBASE
Digital Diagnostics Monitoring (DDM)	Yes

Minimum operating temperature	0 °C
Maximum operating temperature	70 °C
