Produktbeskrivning

The FortiGate 4200F series delivers high performance next generation firewall (NGFW) capabilities for large enterprises and service providers. With multiple high-speed interfaces, high-port density, and high- throughput, ideal deployments are at the enterprise edge, hybrid data center core, and across internal segments. Leverage industry-leading IPS, SSL inspection, and advanced threat protection to optimize your network performance. Fortinet’s Security-Driven Networking approach provides tight integration of the network to the new generation of security.



Viktiga egenskaper

Fortinet 8x 100GE/40GE QSFP28 slots and 18x 25GE/10GE SFP28 slots, 2 x GE RJ45 Management Ports, SPU NP7 and CP9 hardware accelerated, and 2 AC power supplies. Firewall throughput: 800 Gbit/s, IPS/IDS throughput: 52000 Mbit/s. Security algorithms: 256-bit AES, HTTPS. Management platform: FortiOS. Connectivity technology: Wired, Console port: RJ-45. Form factor: 3U



Teknisk specifikation

Firewall throughput	800 Gbit/s
IPS/IDS throughput	52000 Mbit/s
Maximum firewall connections per second	1000000
Maximum firewall connections	210000000
Security policies (max)	3.02
Default number of virtual firewalls	10
Maximum number of virtual firewalls	500

Built-in processor	No

Wi-Fi	No

Security algorithms	256-bit AES,HTTPS
Firewall security	Yes

LED indicators	Yes
Management platform	FortiOS

Connectivity technology	Wired
USB 2.0 ports quantity	1
Console port	RJ-45
Number of console ports	1
SFP+ module slots quantity	16
SFP module slots quantity	4

Rack mounting	Yes
Form factor	3U

AC input frequency	50 - 60 Hz

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-35 - 70 °C
Operating relative humidity (H-H)	20 - 90 %

Width	437 mm
Depth	664.8 mm
Height	132.5 mm

Firewall throughput	800000 Mbit/s
