Produktbeskrivning

Layer 2 FortiGate switch controller compatible PoE switch with 24x 2.5G/1G/100M/10M RJ45 ports - 8x 802.3bt (90W) PoE and 16x 802.3af/at (30W) PoE - and 6x 10G/1G SFP+/SFP ports, and 1x RJ45 console port. Max 780W PoE output limit with smart fan/temperature control



Viktiga egenskaper

Fortinet FS-124G-FPOE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 24, Console port: RJ-45. MAC address table: 32000 entries, Switching capacity: 240 Gbit/s. Networking standards: IEEE 802.1AX, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE.... Power over Ethernet (PoE). Rack mounting, Form factor: 1U



Teknisk specifikation

Switch type	Managed
Switch layer	L2

Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
SFP module slots quantity	6
Console port	RJ-45

Networking standards	IEEE 802.1AX,IEEE 802.1D,IEEE 802.1Q,IEEE 802.1ad,IEEE 802.1s,IEEE 802.1w,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ad,IEEE 802.3ae,IEEE 802.3af,IEEE 802.3at,IEEE 802.3az,IEEE 802.3ba,IEEE 802.3bj,IEEE 802.3bm,IEEE 802.3bt,IEEE 802.3bz,IEEE 802.3cd,IEEE 802.3u,IE
10G support	Yes
Link aggregation	Yes
Broadcast storm control	Yes
Flow control support	Yes
VLAN support	Yes
Virtual LAN features	VLAN mapping
Number of VLANs	4000

MAC address table	32000 entries
Switching capacity	240 Gbit/s
Jumbo frames support	Yes
Packet buffer memory	2 MB

DHCP features	DHCP snooping
Access Control List (ACL)	Yes
Loop protection	Yes

Multicast support	Yes

Rack mounting	Yes
Form factor	1U
International Protection (IP) code	IP20

Memory type	DDR4-SDRAM
Internal memory	1024 MB
Flash memory	256 MB
Noise level	48.2 dB

Power source	AC
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (typical)	880 W

Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Total Power over Ethernet (PoE) budget	780 W

Operating temperature (T-T)	-5 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %

Width	440 mm
Depth	310 mm
Height	44 mm
Weight	4860 g
