Security, Performance, and Manageability
The FortiSwitch™ Secure Access Family delivers outstanding security, performance, and manageability. Secure, simple, and scalable, FortiSwitch is the right choice for threatconscious businesses of all sizes.

Tightly integrated into the Fortinet Security Fabric via FortiLink, FortiSwitch can be managed directly from the familiar FortiGate interface. This single-pane-of-glass management provides complete visibility and control of users and devices on the network regardless of how they connect. This makes the FortiSwitch ideal for SD-Branch and campus deployments with applications that range from desktop to data center aggregation, enabling businesses to converge their security and network access.



Viktiga egenskaper

Fortinet FS-624F. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24, Installed SFP+ modules quantity: 4, Console port: RJ-45. MAC address table: 64000 entries, Switching capacity: 440 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Rack mounting, Form factor: 1U



Teknisk specifikation

Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity	4
Console port	RJ-45

Networking standards	IEEE 802.3af,IEEE 802.3at
Routing entries	16000
Link aggregation	Yes
Ethernet LAN data rates	10,100,1000,2500,5000 Mbit/s
Spanning tree protocol	Yes
Number of VLANs	4000

MAC address table	64000 entries
Switching capacity	440 Gbit/s
Latency (1 Gbps)	1 µs
Packet buffer memory	8 MB

Access Control List (ACL) IPv4 entries	36000

Multicast support	Yes
IPv4 multicast entries	12000

Rack mounting	Yes
Form factor	1U
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Memory type	DDR4-SDRAM
Internal memory	4000 MB
Flash memory	32 MB
Noise level	54.88 dB
Mean time between failures (MTBF)	87660 h

Power source	AC
Power supply included	Yes
Number of power supply units	2
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (max)	240 W

Power over Ethernet (PoE)	No

Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	5 - 95 %
Heat dissipation	423 BTU/h

Width	440 mm
Depth	350 mm
Height	44 mm
Weight	6925 g
