Produktbeskrivning

FortiSwitch Data Center switches deliver a secure, simple, scalable Ethernet solution with outstanding throughput, resiliency, and scalability. Virtualization and cloud computing have created dense high-bandwidth Ethernet networking requirements. FortiSwitch Data Center switches meet these challenges by providing a high-performance 10 GE, 40 GE, or 100 GE capable switching platform, with a low total cost of ownership. Ideal for Top of Rack server or firewall aggregation applications, as well as SD-Branch network core deployments, these switches are purpose-built to meet the needs of today’s bandwidth-intensive environments.



Viktiga egenskaper

Fortinet FortiSwitch T1024E. Basic switching RJ-45 Ethernet ports type: 10G Ethernet (100/1000/10000), Basic switching RJ-45 Ethernet ports quantity: 24. MAC address table: 128000 entries, Switching capacity: 480 Gbit/s. Rack mounting, Form factor: 1U



Teknisk specifikation

Basic switching RJ-45 Ethernet ports quantity	24
Basic switching RJ-45 Ethernet ports type	10G Ethernet (100/1000/10000)

10G support	Yes
Link aggregation	Yes
VLAN support	Yes
Number of VLANs	4000

MAC address table	128000 entries
Switching capacity	480 Gbit/s
Latency (10 Gbps)	800 µs
Number of queues	8
Packet buffer memory	9 MB

Rack mounting	Yes
Form factor	1U
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Internal memory	2000 MB

Power supply included	Yes
Redundant power supply (RPS) support	Yes
AC input voltage	100 - 240 V
Power consumption (max)	140 W

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-25 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Heat dissipation	369.87 BTU/h

Width	438.5 mm
Depth	460 mm
Height	43.5 mm
Weight	8000 g
