Produktbeskrivning

48xRJ-45/4xGE SFP, 370W PoE, 16K MAC, 104 Gbit/s, 155 Mpps, 100-240V, 50/60Hz, 393.1W



Viktiga egenskaper

Fortinet L2+ managed POE switch with 48GE +4SFP, 24 ports POE with max 370W POE limit. MAC address table: 16000 entries, Switching capacity: 104 Gbit/s. Networking standards: IEEE 802.3af, IEEE 802.3at. Power over Ethernet (PoE). Rack mounting, Form factor: 1U



Teknisk specifikation

Fiber ports quantity	4
Fiber optic connector	SFP

Networking standards	IEEE 802.3af,IEEE 802.3at
Spanning tree protocol	Yes
Link aggregation	Yes
VLAN support	Yes
Number of VLANs	4000

MAC address table	16000 entries
Switching capacity	104 Gbit/s
Forwarding rate	155 Mpps
Latency (1 Gbps)	3860 µs
Packet buffer memory	1.5 MB

Access Control List (ACL)	Yes

Rack mounting	Yes
Form factor	1U
Product colour	White
Certification	FCC, CE, RCM, VCCI, BSMI, UL, CB, RoHS2

Memory type	DDR3-SDRAM
Internal memory	256 MB
Flash memory	64 MB
Mean time between failures (MTBF)	87600 h

Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	389.742 W
Power consumption (max)	393.109 W

Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) ports quantity	24
Total Power over Ethernet (PoE) budget	370 W

Operating temperature (T-T)	0 - 45 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90 %
Heat dissipation	78.82 BTU/h

Width	440 mm
Depth	348 mm
Height	44 mm
Weight	5200 g
