Produktbeskrivning

The PX940 series takes industrial printing to a new level of accuracy and simplicity by providing customers with error-free precision printing, increasing production efficiency and reducing operational costs.
The PX940 family of high-performance industrial printers with integrated label verification technology provides error-free printing. Developed for companies that are subjected to fines levied for non-compliance to regulatory standards, and returned shipments due to unreadable barcodes, the PX940 series prints barcodes that are defect-free and 100% accurate every time. The fully integrated verifier allows for quick setting up even when printing and verifying different labels. With pass/fail and ANSI grades from 1 to 4, bad labels that do not meet an established threshold are voided and a new label is reprinted. The PX940 printer has print registration of up to +/- 0.2 mm (0.0079 in). The trend toward miniaturization requires printing on smaller and smaller labels. The PX940 will print accurately on small labels, edge to edge with little error tolerance. The PX940 printers are suited for transportation and logistics, pharmaceuticals and healthcare, shipping and distribution centers, industrial manufacturing, automotive parts suppliers, and applications that are regulated and require high precision and error-free printing. The PX940 printer is available in two versions: one with the integrated verifier, and an option without the integrated verifier. Both versions are available with standard features such as Bluetooth®: and smart printing capability, in which users can configure and fine-tune settings without the need for a host computer. With a Honeywell firmware platform that supports multiple print languages, the PX940 printer is an easy replacement for competitive printers. A rugged all-metal print mechanism, and easy printhead and tool-free platen roller replacement, help minimize downtime and maintenance needs. The PX940 printer can support a wide range of media –: including ink-in and ink-out ribbons with one-inch core size –: enabling maximum time between media resupply. Fast time-to-label and print speeds of up to 350 mm/s (14 ips) ensure that the PX940 printer can scale with the changing needs of dynamic operations.



Viktiga egenskaper

Honeywell PX940. Print technology: Direct thermal / Thermal transfer, Maximum resolution: 600 x 600 DPI. Connectivity technology: Wired & Wireless, Ethernet LAN, Bluetooth, USB port. Product colour: Black



Teknisk specifikation

Print technology	Direct thermal / Thermal transfer
Colour	No
Maximum resolution	600 x 600 DPI
Maximum printing width	105.6 mm
Minimum print length	550 mm

Ribbon width	110 mm
Ribbon length	450 m
Maximum roll diameter	80 mm
Core diameter	25.4 mm

Connectivity technology	Wired & Wireless
Ethernet LAN	Yes
Bluetooth	Yes
Bluetooth Low Energy (BLE)	Yes
USB port	Yes
USB 2.0 ports quantity	2

Page description languages	DP,DPL,XML,ZPL II,IPL
Internal memory	1024 MB
Flash memory	256 MB
Built-in processor	Yes

Product colour	Black
Built-in display	Yes
Display	LCD
Display diagonal	3.5 "

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Operating relative humidity (H-H)	20 - 85 %
Operating temperature (T-T)	5 - 40 °C

Width	261 mm
Depth	506 mm
Height	398.7 mm
Weight	23000 g

Cables included	AC

Harmonized System (HS) code	84433210
