Produktbeskrivning

Single-Line Laser Scanner
Built on the platform of the world’s best-selling single-line laser scanner, Honeywell’s Voyager 1200g delivers aggressive scan performance on virtually all linear bar codes, including poor quality and damaged codes. Updated object detection, and automatic in-stand detection and configuration enable class-leading presentation scanning that maximizes throughput. Superior scan performance matched with a reliable design combine to provide a versatile linear scanning solution suitable for a wide variety of applications.

The intuitive Voyager 1200g provides fast and reliable scanning of linear bar codes across its full working range, minimizing the need for user training. Whether poorly printed, smudged or faded, the Voyager 1200g decodes difficult-to-read bar codes with ease. The Voyager 1200g also excels at scanning high density bar codes with resolution down to 3.5 mil, eliminating the need to purchase specialty scanners.

Designed to decrease downtime and service costs, the Voyager 1200g includes a single shock-mounted PCB that delivers greater impact resistance. A recessed button protected by an integrated rubber comold minimizes the impact of accidental drops. Added durability is provided in the form of a protected, scratch-resistant glass window and an IP42-rating.

The Voyager 1200g, the next installment in the world-renowned Voyager series, provides outstanding scan performance and reliability for end users seeking an exceptional linear scanning solution.



Viktiga egenskaper

Honeywell Voyager 1200g. Scanner type: 1D, Light levels (direct sunlight): 0 - 70000 lx, Pitch reading angle: -60 - 60°. Standard interfaces: USB, RS-232, RS-485, Keyboard wedge. Product colour: Grey. Power consumption (standby): 0.35 W. Weight: 125 g, Width: 66 mm, Depth: 180 mm



Teknisk specifikation

Scanner type	1D
Light levels (direct sunlight)	0 - 70000 lx
Pitch reading angle	-60 - 60 °

Standard interfaces	USB,RS-232,RS-485,Keyboard wedge

Product colour	Grey

Power consumption (standby)	0.35 W

Width	66 mm
Depth	180 mm
Height	97 mm
Weight	125 g

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 95 %

Harmonized System (HS) code	84716070
