Produktbeskrivning
Do you need to accelerate the performance of your read intensive applications?
HPE SAS Read Intensive (RI) Solid State Drives (SSDs) deliver enterprise features at an affordable price for applications requiring high read IOPS performance. HPE 12Gb Enterprise SAS RI SSDs transfer data at full duplex (bidirectional) allowing greater I/O bandwidth to alleviate bottlenecks at twice the 6Gb interface of SATA drives.
HPE 12Gb SAS RI SSDs are best suited for mission-critical enterprise applications requiring a strong blend of high read IOPS and low latency. HPE 12Gb Enterprise SAS RI SSDs are ideal for read caching, social media, web servers and boot/swap workloads.
Egenskaper
High performance, exceptional reliability, and efficiency for faster business resultsHPE 12Gb SAS Read Intensive (RI) SSDs are ideal for read caching, social media, web servers and boot/swap. Achieve high IOPS and lower latency to enhance the performance of your data center. Maintain data accuracy with full data-path error detection and surprise power loss protection.
HPE 24Gb enabled SAS SSDs are capable of 2x the performance of 12Gb SAS SSDsNext Generation of SAS interface, based on the SAS-4 specification. HPE 24Gb Enterprise SAS capability relies on a complete ecosystem enablement requiring a 24G SAS controller. HPE 24Gb Enterprise SAS SSDs are compatible with 12Gb Enterprise SAS ecosystem.
Teknisk specifikation
Allmänt
| Typ av enhet | SSD-enhet - hot-swap |
|---|
| Kapacitet | 1.92 TB |
|---|
| NAND-flashminnestyp | Trippelnivåcell (TLC) |
|---|
| Formfaktor | 2.5" SFF |
|---|
| Gränssnitt | SAS 22.5Gb/s |
|---|
| Egenskaper | Digitally Signed Firmware |
|---|
| Höjd | 1.5 cm |
|---|
| Vikt | 500 g |
|---|
| Kombinerad med | HPE Basic Carrier |
|---|
Prestanda
| Antal skrivningar per dag (DWPD) | 1 |
|---|
| SSD-hållbarhet | 3424 TB |
|---|
| Drivenhetsklass | Read Intensive |
|---|
| Hårddiskens överföringshastighet | 2.25 GBps (extern) |
|---|
| Intern datafrekvens | 1080 MBps (läs)/ 1035 MBps (skriv) |
|---|
| 4 KB Random Read | 145000 IOPS |
|---|
| 4 KB Random Write | 79000 IOPS |
|---|
Expansion och anslutningar
| Gränssnitt | 1 x SAS 22.5Gb/s |
|---|
| Kompatibelt fack | 2.5" SFF |
|---|
Strömtillförsel
| Strömkonsumtion | 2.78 Watt (inaktiv)
6.74 Watt (slumpmässig läsning)
6.74 Watt (slumpmässig skrift)
6.47 Watt (sekvensiell läsning)
9.57 Watt (sekvensiell skrift)
6.74 Watt (slumpmässig läsning/skrivning)
9.57 Watt (max) |
|---|
Tillverkarens garanti
| Service och support | Begränsad garanti - 3 år |
|---|
Kompatibilitetsinformation
| Designat för | HPE ProLiant DL325 Gen10 Plus V2 (2.5"), DL325 Gen10 Plus V2 Base (2.5"), DL325 Gen10 Plus V2 for Weka Base Tracking (2.5"), DL325 Gen10 Plus V2 Performance (2.5"), DL345 Gen10 Plus (2.5"), DL345 Gen10 Plus Base (2.5"), DL345 Gen10 Plus Entry (2.5"), DL360 Gen10 Plus (2.5"), DL360 Gen10 Plus All-NVMe Server for Software Defined Storage (2.5"), DL360 Gen10 Plus for Weka Base Tracking (2.5"), DL360 Gen10 Plus Network Choice (2.5"), DL365 Gen10 Plus (2.5"), DL380 Gen10 Plus (2.5"), DL380 Gen10 Plus Network Choice (2.5")
HPE SimpliVity 325 Gen10 Plus V2 Node (2.5") |
|---|
