Produktbeskrivning

Weatherproof and temperature hardened, Aruba 560 series access points deliver cost-effective Wi-Fi 6 wireless connectivity in outdoor and environmentally challenging hazardous locations. Purpose-built to survive in the harshest outdoor environments, 560 series can withstand exposure to extreme high and low temperatures, persistent moisture and precipitation, and are fully sealed to keep out airborne contaminants. All electrical interfaces include industrial strength surge protection. Aruba Wi-Fi 6 access points provide high-performance connectivity for any organization experiencing growing numbers of IoT and mobility requirements. With maximum aggregate on air data rate of 1.49 Gbps (HE80/HE20), they deliver the speed and reliability needed for most environments. Aruba's advanced ClientMatch technology and an integrated Bluetooth beacon can help enable Aruba location services.



Egenskaper

Advantages of OFDMA
OFDMA capability allows Aruba APs to handle multiple Wi-Fi 6 capable clients on each channel simultaneously, regardless of device or traffic type. Channel utilization is optimized by handling each transaction via smaller sub-carriers or resource units (RUs), which means that clients are sharing a channel yet not competing for airtime and bandwidth.

Aruba Air Slice for Extended OFDMA Assurance
Initially, APs in controller-less mode (Instant) can provide SLA-grade performance by allocating radio resources, such as time, frequency, and spatial streams, to specific traffic types. By combining Aruba's Policy Enforcement Firewall (PEF) and Layer 7 deep packet inspection (DPI) to identify user roles and applications, the APs will dynamically allocate the bandwidth needed. Non-Wi-Fi 6 clients can also benefit. For APs, Air Slice uses Aruba Central for management. Controller-based APs will be supported in a future software release.

Multi-User MIMO (MU-MIMO)
560 Series APs support downlink MU-MIMO just like Wi-Fi 5 (802.11ac Wave 2) APs. The added benefit is the ability to multiply the number of clients that can now send traffic, thus optimizing client-to-AP spatial stream diversity.

Wi-Fi 6 and MU-MIMO aware client optimization
Aruba's patented AI-powered ClientMatch technology eliminates sticky client issues by placing Wi-Fi 6 capable devices on the best available AP. Session metrics are used to steer mobile devices to the best AP based on available bandwidth, types of applications being used and traffic type - even as users roam.

Aruba Advanced Cellular Coexistence (ACC)
The ACC feature uses built-in filtering to automatically minimize the impact of interference from cellular networks, distributed antenna systems (DAS), and commercial small cell or femtocell equipment.

Intelligent Power Monitoring (IPM)
Aruba APs continuously monitor and report hardware energy consumption. They can also be configured to enable or disable capabilities based on available PoE power - ideal when wired switches have exhausted their power budget.



Teknisk specifikation

Typ av enhet	Trådlös åtkomstpunkt
Robust design	Utomhus
Bredd	16.5 cm
Djup	16.5 cm
Höjd	11 cm
Vikt	1.03 kg

Formfaktor	Extern
Anslutningsteknik	Trådlös
Dataöverföringshastighet	1.2 Gbps
Linjekodningsformat	CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, OFDMA
Datalänkprotokoll	IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, ZigBee, IEEE 802.11ac Wave 2, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Metod för spridningsspektrum	OFDM, DSSS, OFDMA
Nätverks/transportprotokoll	IPSec
Frekvensband	2.4 GHz, 5 GHz
Prestanda	Maximal datahastighet (5 GHz): 1,2 Gbps Maximal datahastighet (2,4 GHz): 574 Mbps Aggregerad datahastighet: 1,49 Gbps
Kapacitet	Trådlösa klienter per trådlös radio: 256 BSSID:er per radio: 16 OFDMA-enheter: 16
Statusindikatorer	System, status, radio
Funktioner	Auto-uplink (auto MDI/MDI-X), stöd för DFS, ingående paketinspektion (DPI), Trusted Platform Module (TPM), återställningsknapp, Maximum Ratio Combining (MRC), Low Density Parity Check (LDPC), redo för strålformssändning (TxBF), Direct Sequence Spread Spectrum (DSSS), Cyclic Delay Diversity (CDD), Space Time Blocking Code (STBC), Virtual Mobility Controller-läge, Advanced Cellular Coexistence (ACC), ClientMatch, cyklisk växlingsmångfald (CSD), MU-MIMO-teknik, paketaggregering A-MPDU, paketaggregering A-MSDU, SU-MIMO-teknologi, Intelligent Power Monitoring (IPM), Dynamic Frequency Selection (DFS), stöd för hög genomströmning (HT), Zero-touch provisioning (ZTP), EEE (Energy-Efficient Ethernet), Orthogonal Frequency Division Multiplexing (OFDM), vattentät, 2x2 MIMO-teknik, stöd för mycket hög genomströmning (VHT) support, Orthogonal Frequency Division Multiple Access (OFDMA), högeffektiv support (HE), målväntetid (TWT), härdad, Wi-Fi 6-teknik, Policy Enforcement Firewall (PEF), Layer 7 Deep Packet Inspection (DPI), Passpoint Release 2
Krypteringsalgoritm	SSL, WPA3, WPA3-Enhanced Open, WPA2-MPSK
Standarder som följs	IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.3at, IEEE 802.3az, IEEE 802.11ac Wave 2, IEEE 802.3bz, IEEE 802.11ax, Wi-Fi CERTIFIED 6

Antenn	Inbyggd
Riktning	Rundstrålande
Förstärkningsnivå	5.4 dBi

Kompatibel med Internet of Things (IoT)	Ja
Kommunikationsteknologi	Zigbee

Gränssnitt	1 x 1000Base-T (PoE+) - RJ-45 1 x konsol - USB-C

Standarder som följs	FCC, EN 60601-1-2, IP67, IP66, EN 60601-1-1, EMC 2014/30/EU, LVD 2014/35/EU, ISED, IEC/EN/UL 60950, RED 2014/53/EU
Typ av prissättning	BTO

Stöd för PoE (Power Over Ethernet)	PoE Class 3
Energiförbrukning vid drift	15.6 Watt

Operativsystem erfordras	ArubaOS, InstantOS

Service och support	Begränsad garanti - livstid

Min temperatur vid drift	-40 °C
Max temperatur vid drift	55 °C
Luftfuktighet vid drift	5 - 95 % (icke-kondenserande)
