Produktbeskrivning

Do you need to accelerate the performance of your mixed-use applications?

HPE NVMe High Performance Mixed Use (MU) SSDs are best suited for high I/O applications that require a balanced performance between reads and writes to deliver high performance and endurance for data intensive applications. NVMe High Performance MU SSDs communicate directly to applications via the PCIe bus to boost I/O bandwidth and reduce latency.

HPE NVMe High Performance MU SSDs deliver high performance, lower latency data transfers from storage significantly faster than SAS or SATA SSDs. Utilizes the high bandwidth of PCIe Gen3 and PCIe Gen4 in select servers for mixed use workloads such as Big Data analytics, HPC and virtualization.

HPE SSDs are backed by up to 3.35 million hours of testing and qualification ensuring reliable, high performing drives. HPE Digitally Signed Firmware prevents unauthorized access to data by providing the assurance that drive firmware comes from a trusted source.



Egenskaper

● HPE NVMe High Performance Mixed Use (MU) Solid State Drives are ideal for Big Data analytics, cloud computing, high performance compute, business intelligence, database applications and virtualization
● Achieve higher IOPS and lower latency to enhance the performance of your data center
● Maintain data accuracy with full data-path error detection
● Choose from a broad portfolio of enhanced solutions in a wide variety of capacities
● HPE NVMe High Performance SSDs, M.2, and M.2 Enablement Kits



Teknisk specifikation

Typ av enhet	SSD-enhet - hot-swap
Kapacitet	6.4 TB
NAND-flashminnestyp	Trippelnivåcell (TLC)
Formfaktor	2.5" SFF
Gränssnitt	PCIe (NVMe)
Egenskaper	Digitally Signed Firmware
Höjd	15 mm
Vikt	680 g
Kombinerad med	HPE Smart Carrier NVMe

Antal skrivningar per dag (DWPD)	3
SSD-hållbarhet	34242 TB
Intern datafrekvens	6500 MBps (läs)/ 3800 MBps (skriv)
4 KB Random Read	930000 IOPS
4 KB Random Write	340000 IOPS

Gränssnitt	1 x PCI Express (NVMe)
Kompatibelt fack	2.5" SFF

Strömkonsumtion	6.3 Watt (inaktiv) 17.8 Watt (slumpmässig läsning) 18 Watt (slumpmässig skrift) 16 Watt (sekvensiell läsning) 18.8 Watt (sekvensiell skrift) 15.5 Watt (slumpmässig läsning/skrivning) 18.8 Watt (max)

Service och support	Begränsad garanti - delar - 3 år

Designat för

HPE Nimble Storage dHCI Large Solution with HPE ProLiant DL380 Gen10 (2.5"), Medium Solution with HPE ProLiant DL360 Gen10 (2.5"), Small Solution with HPE ProLiant DL360 Gen10 (2.5") HPE ProLiant DL325 Gen10 (2.5"), DL325 Gen10 Base (2.5"), DL325 Gen10 Entry (2.5"), DL325 Gen10 Performance (2.5"), DL325 Gen10 SMB Solution (2.5"), DL325 Gen10 Solution (2.5"), DL360 Gen10 All Flash Server for Datera (2.5"), DL360 Gen10 All Flash Server for Weka (2.5"), DL360 Gen10 Compute Server for Cohesity DataPlatform (2.5"), DL360 Gen10 Low (2.5"), DL360 Gen10 Network Choice (2.5"), DL360 Gen10 Network Choice for SAP HANA Compute Block (2.5"), DL360 Gen10 Performance for Cohesity DataPlatform (2.5"), DL360 Gen10 Premium (2.5"), DL360 Gen10 Remote Office Branch Office Server for Cohesity DataPlatform (2.5"), DL360 Gen10 Server for CTERA (2.5"), DL360 Gen10 SMB (2.5"), DL360 Gen10 SMB Network Choice (2.5"), DL360 Gen10 Solution (2.5"), DL360 Gen10 Special Server (2.5"), DL380 Gen10 All Flash Server for Datera (2.5"), DL380 Gen10 Entry SMB (2.5"), DL380 Gen10 for Cohesity DataPlatform (2.5"), DL380 Gen10 for SAP HANA Compute Block (2.5"), DL380 Gen10 Hybrid Server for Datera (2.5"), DL380 Gen10 Network Choice (2.5"), DL380 Gen10 Network Choice for CTERA (2.5"), DL380 Gen10 Network Choice for SAP HANA Compute Block (2.5"), DL380 Gen10 NVMe All Flash Server for Datera (2.5"), DL380 Gen10 Server for CTERA (2.5"), DL380 Gen10 SMB (2.5"), DL380 Gen10 SMB Networking Choice (2.5"), DL380 Gen10 Solution (2.5"), DL385 Gen10 (2.5"), DL385 Gen10 Base (2.5"), DL385 Gen10 High-Performance (2.5"), DL385 Gen10 Performance (2.5"), DL385 Gen10 SMB (2.5"), DL385 Gen10 Solution (2.5"), DL560 Gen10 for SAP HANA Compute Block (2.5"), ML350 Gen10 High Performance (2.5"), ML350 Gen10 SMB (2.5"), ML350 Gen10 Solution (2.5"), ML350 Gen10 Special Server (2.5") HPE Synergy 480 Gen10 Compute Module (2.5"), 660 Gen10 Compute Block (2.5")
