Produktbeskrivning

How can you provide fast, reliable and cost-effective connectivity in the data center with predictable performance and investment protection? The HPE StoreFabric SN2100M switches are ideal for modern server and storage networks. Supporting up to 128 ports of 10, 25, 40, 50, and 100GbE in 1U, delivering predictable performance and zero packet loss at line-rate across each port and packet size. Optimized for storage combined with efficient design provide enterprise-level performance with attractive economics and outstanding ROI. Networks built on the HPE SN2100M are fast, reliable, and scalable while also being affordable and easily managed. It supports all types of primary and secondary storage, providing consistently fair, fast, low-latency connectivity even under heavy workloads or a mix of different port speeds. This makes them ideal for storage, hyper converged, financial services, and media and entertainment deployments.



Egenskaper

Superior performance with future proof growth
The HPE StoreFabric SN2100M switches provide predictability within a storage network and consistent throughput regardless of the packet size being transferred, the mixture of ports which are sending data and even within mixed speed environments. Provides wire-rate performance with zero packet loss across all frame sizes, avoiding any negative impact on applications that could occur with frame loss as unexpected packet loss is unacceptable in modern data centers, especially within a storage network. Capable of forwarding 100% capacity wire rate performance with zero packet loss across all ports concurrently at 100GbE speeds while transferring data across both Layer 2 and Layer 3 networks. Can be deployed to support 10GbE ports and is designed to be able to evolve over time to support 25, 50, and 100GbE speeds. This helps future proof your network architecture and allows for implementing significant speed changes to the architecture over time.

Optimized for storage and hyper converged environments
The HPE StoreFabric SN2100M switches provide high port density in a single rack unit, allowing for higher capacity and efficiency, simplifying scale-out environments and saving on total cost of ownership. Unique break-out cables fan out individual switch ports to multiple device ports. With unique form factors and port counts, these Ethernet switches allow for two HPE SN2100 units to be deployed side-by-side allowing for increased density, making it the ideal top-of-rack switch. Designed to use less electric power than competing switches, with less than 150 W per port providing one of the industry's lowest power draws, producing less heat than competing products allowing reduced OpEx cost.

Unleashes flash storage performance
The HPE StoreFabric SN2100M switches provide ultra-low latency of under 300ns port-to-port. This is advantageous for flash storage which moved latency form storage access to the network, as well as for the burst nature of today's software defined and cloud data centers traffic. Provides enough internal bandwidth that there is sufficient capacity to carry all ports at 100 Gb/s bandwidths concurrently. This allows the switches to avoid head-of-line blocking which can reduce overall performance and throughput.



Teknisk specifikation

Typ av enhet	Switch - 8 portar - L3 - Administrerad
Modell	Rackmonterbar 1U
Undertyp	100 Gigabit Ethernet
Portar	8 x 100 Gigabit QSFP28
Prestanda	Växlingskapacitet: 3,2 Tbps Bearbetningshastighet: 4,76 Bpps Genomslagslatens: 300 ns
Protokoll för administration på distans	SNMP, Telnet, SSH, CLI
Verifieringsmetod	RADIUS, TACACS+, LDAP
Funktioner	IGMP snooping, portspegling, lagra och vidarebefordra, stöd för IPv6, stöd för RSTP (Rapid Spanning Tree Protocol), stöd för VRRP (Virtual Route Redundancy Protocol), stöd för MSTP (Multiple Spanning Tree Protocol), stöd för DCBX (Data Center Bridging Exchange ), stöd för Access Control List (ACL), Quality of Service (QoS), Bidirectional Forwarding Detection (BFD), IPv4-support, LLDP-support, DHCP-relä, sFlow v5, 802.1x-autentisering, 16 MB paketbuffert, OpenFlow-support, Protokollbaserad VLAN-support, Storm Control, RDMA over Converged Ethernet (RoCE), random early detection (RED), Explicit Congestion Notification (ECN), Priority-Based Flow Control (PFC), Virtual Extensible LAN (VXLAN), Multi Chassis Link Aggregation Group (MLAG), Open Shortest Path First (OSPF), Root Guard, Loop Guard, Voice VLAN, Top-of-Rack (ToR), STP BPDU Guard, BPDU Filter, Protocol Independent Multicast (PIM)
Standarder som följs	X.509
RAM	8 GB
Flash-minne	16 MB
Statusindikatorer	System, status, fläkt

Gränssnitt	8 x 100Gbit LAN QSFP28 8 x 100Gbit LAN QSFP28 möjlighet till ytterligare port 1 x hantering RJ-45 1 x konsol RJ-45 1 x USB mini-USB

Nätdel	Intern strömförsörjning
Installerat antal	2
Max antal som stöds	2
Redundant ström	Ja
Schema för redundant ström	1+1
Nätspänning	AC 120/230 V (50/60 Hz)
Energiförbrukning vid drift	94 Watt

Inkluderade tillbehör	2 strömkablar (C13 till C14)
Medföljande kablar	1 x seriell kabel
Rackmonteringssats	Tillval
Standarder som följs	EMC, FIPS 140-2, X.509, EN 61000-4-5:2006, EN 61000-4-11:2004, UL 60950-1:2007, EN 61000-3-3:2013, EN 55024:2010, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-6:2014, EN 61000-3-2:2014, IEC60950-1:2005, Second edition + Am1:2009 + Am2:2013, VCCI V-3/2015.04 Class A, EN 55032:2012 Class A, ICES-003:2016 issue 6 Class A, LV, TR CU 020/2011, TR CU 004/2011, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+AC:2011+A2:2013, CAN/CSA C22.2 No. 60950-1:2007+A1:2011+A2:2014, DSTU EN 55032:2014, DSTU EN 60950-1:2014, EN 61000-4-2:2002, EN 61000-4-4:2004+A1:2010, FCC CFR47 Part 15 B 2017 Class A, AS/NZS CISPR32:2015 Class A, KN22:2009 Class A, KN24:2009
Lokalisering	Danska / Danmark

Bredd	20 cm
Djup	50.8 cm
Höjd	4.39 cm
Vikt	4.53 kg

Service och support	Begränsad garanti - material och tillverkning - 3 år - på platsen

Min temperatur vid drift	0 °C
Max temperatur vid drift	40 °C
Luftfuktighet vid drift	10 - 85 % (icke-kondenserande)

Designat för	HPE J2000 Dual IOM 2x100GbE NVMe-oF SFF JBOF Storage, J2000 Dual IOM 6x100GbE NVMe-oF SFF JBOF Storage HPE Apollo 4200 Gen10 192TB Qumulo Hybrid Node, 4200 Gen10 336TB Archive Node with 25Gb NIC for Qumulo, 4200 Gen10 Qumulo Archive Node, 4200 Gen10 Qumulo Hybrid Node, 4200 Qumulo Archive Node, 4200 Qumulo Hybrid Node, 4200 Qumulo Node
