Produktbeskrivning

Boxed Intel Core Ultra 5 processor 250K Plus (30M Cache, up to 5.30 GHz) FCLGA18W



Viktiga egenskaper

Intel Core Ultra 5 250K Plus. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Box. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 30 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 256 GB, Memory types supported by processor: DDR5-SDRAM. On-board graphics card model: Intel® Graphics, On-board graphics card base frequency: 300 MHz, On-board graphics card dynamic frequency (max): 1900 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0



Teknisk specifikation

Processor manufacturer	Intel
Processor family	Intel Core Ultra 5
Processor generation	Intel Core Ultra (Series 2)
Processor model	250K Plus
Processor cores	18
Processor socket	LGA 1851 (Socket V1)
Processor threads	18
Processor operating modes	64-bit
Low Power Efficient-cores	0
Performance cores	6
Efficient cores	12
Processor boost frequency	5.3 GHz
Performance-core boost frequency	5.3 GHz
Performance-core base frequency	4.2 GHz
Efficient-core boost frequency	4.6 GHz
Efficient-core base frequency	3.3 GHz
Processor cache	30 MB
Processor cache type	Smart Cache
Processor base power	125 W
Maximum turbo power	159 W
AI software frameworks supported by CPU	DirectML,OpenVINO,Windows ML,ONNX RT,WebNN
Maximum number of DMI lanes	8
Processor codename	Arrow Lake
Processor ARK ID	245694

Neural processor unit (NPU)	Intel AI Boost
Sparsity support	Yes
Windows Studio effects support	Yes
AI software frameworks supported by NPU	DirectML,OpenVINO,Windows ML,ONNX RT,WebNN
Total processor performance up to	30 TOPs
NPU performance up to	13 TOPs
GPU performance up to	8 TOPs

Maximum internal memory supported by processor	256 GB
Memory types supported by processor	DDR5-SDRAM
Memory channels	Dual-channel
ECC	Yes

Discrete graphics card	No
On-board graphics card	Yes
On-board graphics card model	Intel® Graphics
On-board graphics card base frequency	300 MHz
On-board graphics card dynamic frequency (max)	1900 MHz
Number of displays supported (on-board graphics)	4
On-board graphics card DirectX version	12.0
On-board graphics card OpenGL version	4.5
On-board graphics card maximum resolution (DisplayPort)	7680 x 4320 pixels
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel)	120 Hz
On-board graphics card refresh rate at maximum resolution (DisplayPort)	60 Hz
On-board graphics card refresh rate at maximum resolution (HDMI)	60 Hz
On-board graphics card ID	0x7D67
Discrete graphics card model	Not available
Hardware encode/decode codecs supported	H.264,H.265 (HEVC)
Xe-cores	4
AI software frameworks supported by GPU	DirectML,OpenVINO,Windows ML,ONNX RT,WebGPU
AV1 encode/decode	Yes

Execute Disable Bit	Yes
Thermal Monitoring Technologies	Yes
Idle States	Yes
Market segment	Desktop
Use conditions	Workstation,PC/Client/Tablet
Maximum number of PCI Express lanes	24
PCI Express slots version	4.0,5.0
Supported instruction sets	AVX 2.0,SSE4.1,SSE4.2
Thermal solution specification	PCG 2020A
Scalability	1S
Embedded options available	No
Direct Media Interface (DMI) Revision	4.0

Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Speed Shift Technology	Yes
Intel® Quick Sync Video Technology	Yes
Intel Trusted Execution Technology	Yes
Enhanced Intel SpeedStep Technology	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Turbo Boost Technology	2.0
Intel® Thunderbolt 4	Yes
Intel® Control-flow Enforcement Technology (CET)	Yes
Intel® Thread Director	Yes
Intel® Volume Management Device (VMD)	Yes
Intel® Active Management Technology (Intel® AMT)	Yes
Intel® One-Click Recovery	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel® Virtualization Technology with Redirect Protection (VT-rp)	Yes
Intel® Stable IT Platform Program (SIPP)	Yes
Intel 64	Yes
Intel® Secure Key	Yes
Intel® Boot Guard	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® OS Guard	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU	Yes
Intel® vPro™ Platform Eligibility	Yes
Intel® Remote Platform Erase (RPE)	Yes
Intel® Deep Learning Boost (Intel® DL Boost) on GPU	Yes
Intel® Standard Manageability (ISM)	Yes
Mode-based Execute Control (MBE)	Yes
Intel® Threat Detection Technology (TDT)	Yes
Intel vPro® Enterprise Platform Eligibility	Yes
Intel® Total Memory Encryption - Multi Key	Yes

Maximum operating temperature	105 °C

Package type	Box

OpenCL version	3.0
Status	Launched
Launch date	Q1'26

Processor package size	45 x 37.5 mm

Maximum internal memory	256 GB
L2 cache	30720 KB
Graphics output	eDP1.4b, DP 2.1 UHBR20, HDMI 2.1 FRL
