Produktbeskrivning

iWARP/RDMA
iWARP delivers converged, low-latency fabric services to data centers through Remote Direct Memory Access (RDMA) over Ethernet. The key iWARP components that deliver low-latency are Kernel Bypass, Direct Data Placement, and Transport Acceleration.

Intel® Data Direct I/O Technology
Intel® Data Direct I/O Technology is a platform technology that improves I/O data processing efficiency for data delivery and data consumption from I/O devices. With Intel DDIO, Intel® Server Adapters and controllers talk directly to the processor cache without a detour via system memory, reducing latency, increasing system I/O bandwidth, and reducing power consumption.

PCI-SIG* SR-IOV Capable
Single-Root I/O Virtualization (SR-IOV) involves natively (directly) sharing a single I/O resource between multiple virtual machines. SR-IOV provides a mechanism by which a Single Root Function (for example a single Ethernet Port) can appear to be multiple separate physical devices.

Flexible Port Partitioning
Flexible Port Partitioning (FPP) technology utilizes industry standard PCI SIG SR-IOV to efficiently divide your physical Ethernet device into multiple virtual devices, providing Quality of Service by ensuring each process is assigned to a Virtual Function and is provided a fair share of the bandwidth.

Virtual Machine Device Queues (VMDq)
Virtual Machine Device Queues (VMDq) is a technology designed to offload some of the switching done in the VMM (Virtual Machine Monitor) to networking hardware specifically designed for this function. VMDq drastically reduces overhead associated with I/O switching in the VMM which greatly improves throughput and overall system performance



Viktiga egenskaper

Intel Ethernet Network Adapter E810-XXVDA4T. Internal. Connectivity technology: Wired, Host interface: PCI Express, Interface: Fiber. Maximum data transfer rate: 25000 Mbit/s



Teknisk specifikation

Connectivity technology	Wired
Host interface	PCI Express
Interface	Fiber
Fiber optic connector	SFP28
Fiber ports quantity	4
PCI version	4.0

Maximum data transfer rate	25000 Mbit/s
Ethernet interface type	Gigabit Ethernet,10 Gigabit Ethernet,25 Gigabit Ethernet
Ethernet LAN data rates	1000,10000,25000 Mbit/s
iSCSI support	Yes
LAN controller	Intel E810

Internal	Yes

Compatible operating systems	https://www.intel.com/content/www/us/en/support/articles/000025890/ethernet-products.html (Advanced timing features available in Linux only)
Linux operating systems supported	Yes

Cable type	SFP28 ports - DAC, Optics, and AOCs
Market segment	Server
Intel Virtualization Technology for Connectivity (VT-c)	Yes
Intel Flexible Port Partitioning	Yes
Intel Data Direct I/O Technology	Yes
On-chip QoS and Traffic Management	Yes
Embedded options available	No
iWARP/RDMA	Yes
PCI-SIG* SR-IOV Capable	Yes
Intelligent Offloads	Yes
Intel Virtual Machine Device Queues (VMDq)	Yes
Commodity Classification Automated Tracking System (CCATS)	NA
Bracket height	Full-Height (FH)
Export Control Classification Number (ECCN)	5A991
Speed & slot width	16.0 GT/s, x16 Lane
Processor family	25GbE Intel Ethernet Network Adapter E810-25GbE Intel Ethernet Network Adapter E810
Product brief URL	https://cdrdv2.intel.com/v1/dl/getContent/641626
Launch date	Q1'22
Storage Over Ethernet	iSCSI, NFS
Network interface card cable medium	Copper, Fiber
Status	Launched
