Produktbeskrivning
The latest Intel® Core™ Ultra processors (Series 2) enable you to use the most AI experiences across desktop, mobile and edge—making everything you do easier, faster, and better.
Viktiga egenskaper
Intel Core Ultra 5 225F. Processor family: Intel Core Ultra 5, Processor socket: LGA 1851 (Socket V1), Package type: Box. Neural processor unit (NPU): Intel AI Boost, AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN, Total processor performance up to: 19 TOPs. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR5-SDRAM. Market segment: Desktop, Use conditions: PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. L2 cache: 22528 KB, Maximum internal memory: 192 GB
Teknisk specifikation
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel Core Ultra 5 |
|---|
| Processor generation | Intel Core Ultra (Series 2) |
|---|
| Processor model | 225F |
|---|
| Processor cores | 10 |
|---|
| Processor socket | LGA 1851 (Socket V1) |
|---|
| Processor threads | 10 |
|---|
| Processor operating modes | 64-bit |
|---|
| Performance cores | 6 |
|---|
| Efficient cores | 4 |
|---|
| Processor boost frequency | 4.9 GHz |
|---|
| Performance-core boost frequency | 4.9 GHz |
|---|
| Performance-core base frequency | 3.3 GHz |
|---|
| Efficient-core boost frequency | 4.4 GHz |
|---|
| Efficient-core base frequency | 2.7 GHz |
|---|
| Processor cache | 20 MB |
|---|
| Processor cache type | Smart Cache |
|---|
| Processor base power | 65 W |
|---|
| Maximum turbo power | 121 W |
|---|
| AI software frameworks supported by CPU | DirectML,OpenVINO,Windows ML,ONNX RT,WebNN |
|---|
| Maximum number of DMI lanes | 8 |
|---|
| Processor codename | Arrow Lake |
|---|
| Processor ARK ID | 241069 |
|---|
Neural processor unit (NPU)
| Neural processor unit (NPU) | Intel AI Boost |
|---|
| Sparsity support | Yes |
|---|
| Windows Studio effects support | Yes |
|---|
| AI software frameworks supported by NPU | DirectML,OpenVINO,Windows ML,ONNX RT,WebNN |
|---|
| Total processor performance up to | 19 TOPs |
|---|
| NPU performance up to | 13 TOPs |
|---|
Memory
| Maximum internal memory supported by processor | 192 GB |
|---|
| Memory types supported by processor | DDR5-SDRAM |
|---|
| Memory clock speeds supported by processor | 6400 MHz |
|---|
| Memory channels | Dual-channel |
|---|
Graphics
| On-board graphics card | No |
|---|
| Discrete graphics card | No |
|---|
| On-board graphics card model | Not available |
|---|
| Discrete graphics card model | Not available |
|---|
Features
| Idle States | Yes |
|---|
| Execute Disable Bit | Yes |
|---|
| Thermal Monitoring Technologies | Yes |
|---|
| Market segment | Desktop |
|---|
| Use conditions | PC/Client/Tablet |
|---|
| Maximum number of PCI Express lanes | 24 |
|---|
| PCI Express slots version | 4.0,5.0 |
|---|
| Supported instruction sets | AVX 2.0,SSE4.1,SSE4.2 |
|---|
| Embedded options available | No |
|---|
| Direct Media Interface (DMI) Revision | 4.0 |
|---|
| Scalability | 1S |
|---|
Processor special features
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
|---|
| Intel® Speed Shift Technology | Yes |
|---|
| Intel Trusted Execution Technology | Yes |
|---|
| Intel® Turbo Boost Technology | 2.0 |
|---|
| Intel® Thunderbolt 4 | Yes |
|---|
| Intel® Control-flow Enforcement Technology (CET) | Yes |
|---|
| Intel® Thread Director | Yes |
|---|
| Intel® Secure Key | Yes |
|---|
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
|---|
| Intel® Boot Guard | Yes |
|---|
| Intel® OS Guard | Yes |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|
| Intel® Standard Manageability (ISM) | Yes |
|---|
| Intel® Volume Management Device (VMD) | Yes |
|---|
| Intel Virtualization Technology (VT-x) | Yes |
|---|
| Intel 64 | Yes |
|---|
| Mode-based Execute Control (MBE) | Yes |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
|---|
Operational conditions
| Maximum operating temperature | 105 °C |
|---|
Packaging data
| Package type | Box |
|---|
Technical details
| Status | Launched |
|---|
| Launch date | Q1'25 |
|---|
Other features
| Maximum internal memory | 192 GB |
|---|
| L2 cache | 22528 KB |
|---|
