Produktbeskrivning

Orthogonal Frequency-Division Multiple Access (OFDMA)
Orthogonal Frequency-Division Multiple Access (OFDMA) is a multi-user version of the popular orthogonal frequency-division multiplexing (OFDM) digital modulation scheme. This allows simultaneous low-data-rate transmission from several users.



Viktiga egenskaper

Intel Wi-Fi 7 BE200. Internal. Connectivity technology: Wireless, Host interface: M.2, Interface: WLAN / Bluetooth. Maximum data transfer rate: 5800 Mbit/s, Top Wi-Fi standard: Wi-Fi 7 (802.11be), Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz). Antenna type: 2x2



Teknisk specifikation

Connectivity technology	Wireless
Host interface	M.2
Interface	WLAN / Bluetooth

Maximum data transfer rate	5800 Mbit/s
Networking standards	IEEE 802.11a,IEEE 802.11ac,IEEE 802.11ax,IEEE 802.11az,IEEE 802.11b,IEEE 802.11be,IEEE 802.11d,IEEE 802.11e,IEEE 802.11g,IEEE 802.11h,IEEE 802.11i,IEEE 802.11k,IEEE 802.11n,IEEE 802.11r,IEEE 802.11u,IEEE 802.11v,IEEE 802.11w
Wi-Fi	Yes
Wi-Fi band	Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Top Wi-Fi standard	Wi-Fi 7 (802.11be)
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac),Wi-Fi 6 (802.11ax),Wi-Fi 6E (802.11ax),Wi-Fi 7 (802.11be)
Security algorithms	AES-CCMP,AES-GCMP,EAP-AKA,EAP-SIM,EAP-TLS,EAP-TTLS,MSCHAPv2,PEAP,WPA2,WPA3
Bluetooth	Yes
Bluetooth version	5.4
MU-MIMO	Yes

Internal	Yes
Component for	PC/Laptop
Antenna type	2x2

Windows operating systems supported	Windows 10,Windows 11
Linux operating systems supported	Yes

Operating temperature (T-T)	0 - 80 °C

Sustainability compliance	Yes

Width	22 mm
Depth	30 mm
Height	2.4 mm
Weight	3.07 g

Compliance certificates	CB,UL

Harmonized System (HS) code	8517620090

Maximum operating temperature	70 °C
Intel Trusted Execution Technology	No
Supported Under vPro	Yes
Embedded options available	No
Ethernet adapter ARK ID	230078
Compliance	FIPS
Commodity Classification Automated Tracking System (CCATS)	740.17B1
Export Control Classification Number (ECCN)	5A992C
Status	Launched
Product brief URL	https://www.intel.com/content/www/us/en/secure/content-details/916611/intel-wi-fi-7-be200-5gig-module-commercial-temperature-embedded-module-product-brief.html?DocID=916611
Launch date	Q3'23
