Produktbeskrivning
Intel® Transactional Synchronization Extensions New Instructions (Intel® TSX-NI) are a set of instructions focused on multi-threaded performance scaling. This technology helps make parallel operations more efficient via improved control of locks in software.
Intel® Identity Protection Technology is a built-in security token technology that helps provide a simple, tamper-resistant method for protecting access to your online customer and business data from threats and fraud. Intel® IPT provides a hardware-based proof of a unique user’s PC to websites, financial institutions, and network services; providing verification that it is not malware attempting to login. Intel® IPT can be a key component in two-factor authentication solutions to protect your information at websites and business log-ins.
Intel® AES New Instructions (Intel® AES-NI) are a set of instructions that enable fast and secure data encryption and decryption. AES-NI are valuable for a wide range of cryptographic applications, for example: applications that perform bulk encryption/decryption, authentication, random number generation, and authenticated encryption.
Viktiga egenskaper
Intel Xeon W-2135. Processor family: Intel® Xeon®, Processor socket: LGA 2066 (Socket R4), Processor lithography: 14 nm. Memory channels: Quad-channel, Maximum internal memory supported by processor: 512 GB, Memory types supported by processor: DDR4-SDRAM. Market segment: Server, PCI Express configurations: 1x16, 1x4, 1x8, Supported instruction sets: SSE4.2, AVX, AVX 2.0, AVX-512. Processor package size: 45mm x 52.5mm. Maximum internal memory: 512 GB, Maximum internal memory: 524288 MB
Teknisk specifikation
Processor
| Processor manufacturer | Intel |
|---|
| Processor family | Intel® Xeon® |
|---|
| Processor model | W-2135 |
|---|
| Processor base frequency | 3.7 GHz |
|---|
| Processor cores | 6 |
|---|
| Processor socket | LGA 2066 (Socket R4) |
|---|
| Processor lithography | 14 nm |
|---|
| Cooler included | Yes |
|---|
| Component for | Server/workstation |
|---|
| Processor threads | 12 |
|---|
| System bus rate | 8 GT/s |
|---|
| Processor operating modes | 64-bit |
|---|
| Processor boost frequency | 4.5 GHz |
|---|
| Processor cache | 8.25 MB |
|---|
| Thermal Design Power (TDP) | 140 W |
|---|
| Stepping | U0 |
|---|
| Bus type | QPI |
|---|
| Number of QPI links | 0 |
|---|
| Memory bandwidth supported by processor (max) | 85.3 GB/s |
|---|
| Processor codename | Skylake |
|---|
| Processor code | SR3LN |
|---|
| Processor ARK ID | 126709 |
|---|
Memory
| Maximum internal memory supported by processor | 512 GB |
|---|
| Memory types supported by processor | DDR4-SDRAM |
|---|
| Memory clock speeds supported by processor | 1600,1866,2133,2400,2666 MHz |
|---|
| Memory channels | Quad-channel |
|---|
| ECC | Yes |
|---|
Graphics
| On-board graphics card | No |
|---|
Features
| Thermal Monitoring Technologies | Yes |
|---|
| Execute Disable Bit | Yes |
|---|
| Idle States | Yes |
|---|
| Market segment | Server |
|---|
| Maximum number of PCI Express lanes | 48 |
|---|
| PCI Express slots version | 3.0 |
|---|
| PCI Express configurations | 1x16,1x4,1x8 |
|---|
| Supported instruction sets | SSE4.2,AVX,AVX 2.0,AVX-512 |
|---|
| CPU configuration (max) | 1 |
|---|
| Physical Address Extension (PAE) | Yes |
|---|
| Embedded options available | No |
|---|
| Scalability | 1S |
|---|
| PCI Express CEM revision | 3.0 |
|---|
| Physical Address Extension (PAE) | 46 bit |
|---|
| Export Control Classification Number (ECCN) | 5A992C |
|---|
| Commodity Classification Automated Tracking System (CCATS) | G077159 |
|---|
Processor special features
| Intel® Memory Protection Extensions (Intel® MPX) | Yes |
|---|
| Intel® Device Protection Technology (Intel® DPT) with Boot Guard | Yes |
|---|
| Intel® Identity Protection Technology (Intel® IPT) | Yes |
|---|
| Enhanced Intel SpeedStep Technology | Yes |
|---|
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
|---|
| Intel® Speed Shift Technology | Yes |
|---|
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
|---|
| Intel Trusted Execution Technology | Yes |
|---|
| Intel Flex Memory Access | No |
|---|
| Intel® Turbo Boost Technology | 2.0 |
|---|
| Intel® Transactional Synchronization Extensions | Yes |
|---|
| Intel TSX-NI | Yes |
|---|
| Intel® OS Guard | Yes |
|---|
| Intel 64 | Yes |
|---|
| Intel® Secure Key | Yes |
|---|
| Intel® Boot Guard | Yes |
|---|
| Conflict-Free processor | Yes |
|---|
| Intel Enhanced Halt State | Yes |
|---|
| Intel® Optane™ Memory Ready | No |
|---|
| Intel Software Guard Extensions (Intel SGX) | No |
|---|
| Intel Virtualization Technology (VT-x) | Yes |
|---|
| Intel Demand Based Switching | Yes |
|---|
| Intel Turbo Boost Max Technology 3.0 | No |
|---|
| Intel® Volume Management Device (VMD) | Yes |
|---|
| Intel® vPro™ Platform Eligibility | Yes |
|---|
| Intel VT-x with Extended Page Tables (EPT) | Yes |
|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
|---|
| Intel Secure Key Technology version | 1.00 |
|---|
| AVX-512 Fused Multiply-Add (FMA) units | 2 |
|---|
| Intel TSX-NI version | 1.00 |
|---|
| Intel Identity Protection Technology version | 1.00 |
|---|
Operational conditions
| Tcase | 64 °C |
|---|
Packaging data
| Package type | Box |
|---|
Technical details
| Processor cache | 8448 KB |
|---|
| Supported memory types | DDR4-SDRAM |
|---|
| Product type | Processor |
|---|
| Maximum memory | 512 GB |
|---|
| Processor brand name | Intel® Xeon® |
|---|
| Product family | Intel Xeon Processors |
|---|
| Bus speed | 8 GT/s |
|---|
| Status | Launched |
|---|
| Intel® Volume Management Device (VMD) version | 1.00 |
|---|
| Number of UPI links | 0 |
|---|
| Intel® Speed Shift Technology version | 1.00 |
|---|
| Launch date | Q3'17 |
|---|
| Last change | 63903513 |
|---|
| Bus type units | GT/s |
|---|
Logistics data
| Harmonized System (HS) code | 85423119 |
|---|
Weight & dimensions
| Processor package size | 45mm x 52.5mm mm |
|---|
Other features
| Maximum internal memory | 524288 MB |
|---|
| Maximum internal memory | 512 GB |
|---|
