Produktbeskrivning

The JUA254 USB™ to HDMI™ Multi-Monitor Adapter works as an external video card, instantly allowing users to attach additional displays via HDMI™ connection without the hassle of a lengthy setup or having to install additional hardware. The USB™ 3.0 Display Adapter can support up to four displays running on the same computer, turning your workstation into a fully-functioning, multi-display powerhouse. This USB™ adapter works as an external video card, instantly allowing additional displays without the hassle of opening the computer casing and installing an external graphics card. You can have a second monitor with an extended display, a mirrored display, a rotational display (rotation mode not available for Mac®), or make it your primary monitor. Now enjoy true 1080p HD resolution through any Windows® or Mac® computer with a USB™ 3.0 port. These adapters are also backwards compatible with USB™ 2.0 resolutions and playback, which are ideal for office applications. The simple plug-and-play function allows you to connect your computer to a second monitor or projector within seconds to create a new visual environment on Windows® 10.



Viktiga egenskaper

j5create JUA254 USB 3.0 HDMI Multi-Monitor Adapter. USB version: 3.2 Gen 1 (3.1 Gen 1), USB connector type: USB Type-A, USB connector gender: Male. Product colour: White, Housing material: Acrylonitrile butadiene styrene (ABS), Cable type: USB 3.0. Power consumption (max): 0.93 W, Output voltage: 5 V. Windows operating systems supported: Windows 10, Windows 7, Windows 8, Windows 8.1, Windows Vista, Windows XP Home, Windows XP Home..., Mac operating systems supported: Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High.... Width: 68.3 mm, Depth: 15 mm, Height: 26 mm



Teknisk specifikation

USB version	3.2 Gen 1 (3.1 Gen 1)
USB connector type	USB Type-A
USB connector gender	Male
DVI output	No
HDMI output	Yes
DisplayPort output	No
Number of displays supported	1
HDMI ports quantity	1
Maximum resolution	2048 x 1152 pixels
Maximum resolution (HDMI)	2048 x 1152 pixels
Supported video modes	1080p
Output colour depth	32 bit
Mirror display mode	Yes
Extended display mode	Yes
Current	0.18 A

Product colour	White
Housing material	Acrylonitrile butadiene styrene (ABS)
Integrated USB cable	Yes
Cable type	USB 3.0

Power consumption (max)	0.93 W
Output voltage	5 V

Windows operating systems supported	Windows 10,Windows 7,Windows 8,Windows 8.1,Windows Vista,Windows XP Home,Windows XP Home x64,Windows XP Professional,Windows XP Professional x64
Mac operating systems supported	Mac OS X 10.10 Yosemite,Mac OS X 10.11 El Capitan,Mac OS X 10.12 Sierra,Mac OS X 10.13 High Sierra,Mac OS X 10.14 Mojave,Mac OS X 10.15 Catalina,Mac OS X 10.15.3 Catalina,Mac OS X 10.8 Mountain Lion,Mac OS X 10.9 Mavericks,Mac OS X 11.0 Big Sur,Mac OS X 1

Width	68.3 mm
Depth	15 mm
Height	26 mm
Weight	25 g
USB cable length	0.08 m

Operating temperature (T-T)	0 - 40 °C

Package width	120 mm
Package depth	97 mm
Package height	25 mm
Package weight	73.5 g

Quick installation guide	Yes
Batteries included	No
Packaging content	1 x JUA254 USB™ to HDMI™ Multi-Monitor Adapter, 1 x Quick Installation Guide

Warranty period	2 year(s)

Products per master (outer) case	20 pc(s)
Master (outer) case GTIN (EAN/UPC)	24712795081071
Master (outer) case width	225 mm
Master (outer) case length	321 mm
Master (outer) case height	180 mm
Master (outer) case gross weight	2160 g
Products per shipping (inner) case	5 pc(s)
Shipping (inner) case width	105 mm
Shipping (inner) case length	150 mm
Shipping (inner) case height	160 mm
Country of origin	Taiwan
Export Control Classification Number (ECCN)	EAR99
