Produktbeskrivning
This high-performance USB4® multi-port hub incorporates the latest USB4® controller offering compatibility with Thunderbolt™ 4 and older USB™ specifications.
With up to 40Gbps of throughput, dynamic data, and display bandwidth allocation for efficient display data flow, you can easily create a high-definition monitor setup. Enjoy up to 8K resolution and access data faster without affecting system performance. Additionally, it has three USB™ SuperSpeed+ 10Gbps ports (1 USB-C® and 2 Type-A) for charging or connecting peripherals. It is also equipped a USB-C® Power Delivery port to charge your laptop and power your connected devices with up to 100W of pass-through power.
Viktiga egenskaper
j5create JCD403 USB4® 8K Multi-Port Hub. Host interface: USB Type-C, Hub interfaces: HDMI, RJ-45, USB 3.2 Gen 2 (3.1 Gen 2) Type-A, USB 3.2 Gen 2 (3.1 Gen 2) Type-C. Data transfer rate: 10000 Mbit/s, Supported graphics resolutions: 3840 x 2160, 7680 x 4320, Maximum resolution (HDMI): 7680 x 4320 pixels. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000,2500 Mbit/s. Power supply type: USB/AC, Power supply: 100 W, Input voltage: 20 V. Width: 51 mm, Depth: 15 mm, Height: 135 mm
Teknisk specifikation
Ports & interfaces
| Ports quantity | 6 |
|---|
| Host interface | USB Type-C |
|---|
| Hub interfaces | HDMI,RJ-45,USB 3.2 Gen 2 (3.1 Gen 2) Type-A,USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
|---|
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
|---|
| HDMI ports quantity | 1 |
|---|
| Ethernet LAN (RJ-45) ports | 1 |
|---|
| USB Type-C DisplayPort Alternate Mode | Yes |
|---|
| I/O ports | 1- USB-C 3.2 Gen2 10Gbps data transmission
1- USB-C power delivery 3.0 100W
2- USB Type-A 3.2 Gen2 10Gbps data transmission
1- 8K HDMI
1- RJ45 2.5 Gigabit Ethernet |
|---|
Features
| Data transfer rate | 10000 Mbit/s |
|---|
| Supported graphics resolutions | 3840 x 2160,7680 x 4320 |
|---|
| Maximum resolution (HDMI) | 7680 x 4320 pixels |
|---|
| Housing material | Aluminium |
|---|
| Product colour | Grey |
|---|
| USB Power Delivery revision | 3.0 |
|---|
| USB Power Delivery up to | 100 W |
|---|
| HD type | 8K Ultra HD |
|---|
| Number of displays supported | 1 |
|---|
| Cable type | Round cable |
|---|
| Country of origin | Taiwan |
|---|
| Plug and Play | Yes |
|---|
| Compatible products | Available Thunderbolt 4, Thunderbolt 3, USB4, and USB-C host laptops.
GPU and video source:
DisplayPort 1.4 alt mode with DSC supports 8K 60 Hz or 4K 144Hz.
DisplayPort 1.4 alt mode without DSC supports 8K 30 Hz or 4K 120 Hz.
* DSC = VESA |
|---|
Network
| Ethernet interface type | Gigabit Ethernet |
|---|
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
|---|
Power
| Power supply type | USB/AC |
|---|
| Input current | 5 A |
|---|
| Power supply | 100 W |
|---|
| Input voltage | 20 V |
|---|
| Output voltage | 20 V |
|---|
| Output current | 4.75 A |
|---|
| Power plug type | Type C |
|---|
System requirements
| Windows operating systems supported | Yes |
|---|
| Mac operating systems supported | Yes |
|---|
Weight & dimensions
| Width | 51 mm |
|---|
| Depth | 15 mm |
|---|
| Height | 135 mm |
|---|
| Weight | 109 g |
|---|
Packaging content
| AC adapter included | No |
|---|
| Quick start guide | Yes |
|---|
| Packaging content | 1 - JCD403 USB4 8K Multi-Port Hub
1 - Quick Installation Guide (QIG) |
|---|
Operational conditions
| Operating temperature (T-T) | -1 - 41 °C |
|---|
| Operating temperature (T-T) | 30 - 116 °F |
|---|
| Storage temperature (T-T) | -17 - 68 °C |
|---|
| Operating relative humidity (H-H) | 0 - 85 % |
|---|
| Storage relative humidity (H-H) | 0 - 85 % |
|---|
Technical details
| Warranty period | 2 year(s) |
|---|
