Egenskaper
Superb picture quality with Ultra HD resolutionWith the resolution of UHD, it makes the color and details of the contents vivid and realistic. In addition, the wide viewing angle applied with an IPS panel, provides clear contents.
Sophisticated slim designThis series is thin in bezel size and thickness, which saves space and enables easy installation. In addition, it increases the immersive experience from the screen and provides a sophisticated design, improving the décor of the space where the product is installed.
High performance with LG webOS 6.0LG webOS 6.0, upgraded in SoC and web engine, is available on UL3J series for a smooth execution of several tasks. LG webOS smart signage platform enhances user convenience with intuitive GUI.
Various sensor connectionLG webOS smart signage platform helps to easily provide value-added solutions by supporting simple connections with external sensors such as GPIO, NFC/RFID, temperature sensors, etc., via USB plug-in.
Remote monitoring and controlThis web-based monitoring solution is user-friendly and allows the user to be at ease. It enables the user to have full access anywhere at any time from their mobile phone and PC under network-accessible environment while having access to both current and past data. It allows the user to monitor the unit, make adjustments and control the unit remotely in real time.
Built-in speakerContents will be enriched with sound effects from built-in speakers, without the need for purchasing or installing external speakers.
Teknisk specifikation
Allmänt
Typ av produkt | LED-bakgrundsbelyst, platt LCD-skärm med integrerat Pro:Idiom |
Energiklass | Klass A+ |
Strömförbrukning (max) | 220 Watt |
Energiförbrukning vid drift | 155 Watt |
Strömkonsumtion (driftläge) | 149 W |
Energikonsumtion per år | 217 kWh |
Diagonalklass | 75" |
Kommersiell användning | Ja - digital skyltning |
Serie | UL3J Series |
Operating System | webOS 6.0 |
TV-tuner | Ingen mottagare |
TV-mottagaravkänning | Nej |
Sensorer | Temperatursensor, ljusstyrkesensor |
Videogränssnitt | HDMI |
HDMI-portskvantitet | 3 portar |
Lägen | Stående läge, liggande läge |
Bildförbättringar | DCI 80 % färgskala |
Design | Slim Design |
Dimensioner | Utan ställ |
Bredd | 167.8 cm |
Djup | 5.99 cm |
Höjd | 96.4 cm |
Vikt | 31.4 kg |
Färg | Askblå |
Display
LCD-skärmteknik | IPS |
Upplösning | 3840 x 2160 |
Visningsformat | 4K UHD (2160p) |
Bildkvot | 16:9 |
Rampris och förhöjningsteknologi | 60 Hz Refresh Rate |
LCD-teknik för bakgrundsbelysning | Direktupplyst LED |
Beläggning | 1% dis |
Bildkontrastförhållande | 1200:1 |
Dynamisk kontrast | 1000000:1 |
Ljusstyrka | 330 cd/m² |
Bildvinkel | 178 grader |
Bildvinkel (vertikal) | 178 grader |
Svarstid | 8 ms |
Bakgrundsbelysningens livslängd | 30,000 timme/timmar |
Kommersiella funktioner | SNMP-support, Integrated Contents Management System (CMS), LG SuperSign Media Editor, kompatibel med SuperSign CMS, SuperSign Control+ kompatibel, SuperSign Control compatible, Real Time Communication (webRTC), Local Key Operation, FailOver, kompatibel med SuperSign WB |
Inställningskloningskapacitet | Ja |
Driftstimmar / dagar | 16 / 7 |
Egenskaper | Image Sticking Minimization (ISM), Crestron Connected Compatible, BEACON technology, fjärrlös åtkomstpunkt |
Ställ och hållare
Monteringsgränssnitt för platt bildskärm | 400 x 400 mm |
Överensstämmer med VESA | Ja |
Mediespelare
USB-port | Ja |
Antal USB-portar | 2 |
Konfiguration | 8 GB |
Fjärrkontroll
Typ | Fjärrkontroll |
Ljudsystem
Ytterligare funktioner | Inbyggd högtalare |
Nätverks- och Internet-multimedia
Anknytningsbarhet | Wi-Fi, LAN |
Anslut och dela | Skärmdelning |
Anslutningar
Anslutningstyp | 3 x HDMI-ingång 2 x USB 2.0 Ljudutgång RS-232C-ingång RS-232C-utgång LAN |
Diverse
Medföljande kablar | Seriell adapter |
Standarder som följs | Plug and Play, FCC klass A-certifierad, CB, EMC, ERP, HDCP 2.2, HDCP 1.4 |
Sustainability Information
EPEAT-kompatibel | EPEAT Bronze |
ENERGY STAR-certifierad | Ja |
Strömtillförsel
Nätdel | Nätaggregat |
Inspänning | AC 100-240 V (50/60 Hz) |
Strömkonsumtionsställ med | 0.5 Watt |
Strömkonsumtion (vid läge av) | 0.5 Watt |
Funktioner | WOL (Wake on LAN) |
Mått och vikt (brutto)
Bredd (brutto) | 182 cm |
Djup (brutto) | 20 cm |
Höjd (brutto) | 111.5 cm |
Vikt (brutto) | 40.3 kg |
Miljöparametrar
Min temperatur vid drift | 0 °C |
Max temperatur vid drift | 40 °C |
Luftfuktighet vid drift | 10 - 80% |
