Produktbeskrivning

Rally Bar Mini



Viktiga egenskaper

Logitech Rally Bar Mini. HD type: 4K Ultra HD, Supported video modes: 576p, 720p, 900p, 1440p, 2160p, Maximum frame rate: 30 fps. Digital zoom: 4x. Ethernet LAN, Wi-Fi. Display: IPS, Display diagonal: 25.6 cm (10.1"), Display resolution: 1280 x 800 pixels. Product colour: Graphite



Teknisk specifikation

Product colour	Graphite
Pan range	-25 - 25 °
Tilt angle range	-15 - 15 °
PTZ control	Yes

HD type	4K Ultra HD
Maximum video resolution	3840 x 2160 pixels
Supported video modes	576p,720p,900p,1440p,2160p
Maximum frame rate	30 fps

Built-in speaker(s)	Yes
Output level	92/99 dB
Line-out impedance	4 Ω
Output voltage Total Harmonic Distortion (THD)	2 %
Audio beamforming	Yes
Echo cancellation	Yes
Driver diameter	70 mm
RMS rated power	8 W
Noise reduction	Yes
Sample rates	0 - 48 kHz
Microphone pick-up range	4.5 m

HDMI ports quantity	3
HDMI input ports quantity	1
HDMI output ports quantity	2
USB connector type	USB Type-A,USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	1
DC-in jack	Yes
Microphone in	Yes

Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
Wi-Fi	Yes
Wi-Fi standards	802.11a,802.11b,802.11g,Wi-Fi 4 (802.11n),Wi-Fi 5 (802.11ac)
Supported network protocols	IPv4, IPv6
Security algorithms	128-bit AES

Zoom capability	Yes
Digital zoom	4 x
Horizontal field of view	113 °
Vertical field of view	80.7 °
Diagonal field of view	120 °
Remote control interface	Bluetooth

Display	IPS
Display diagonal	10.1 "
Display resolution	1280 x 800 pixels
Contrast ratio (typical)	1000:1
Touchscreen	Yes
Touchscreen type	Capacitive
Viewing angle, vertical	85 °
Display brightness	400 cd/m²
Viewing angle, horizontal	85 °
Oleophobic coating	Yes

Microphone sensitivity	-36 dB
Microphone frequency	90 - 16000 Hz
Microphone direction type	Omnidirectional
Sound pressure level (max)	90 dB
Number of microphones	6

Telepresence	No
Motion sensor	Yes
Cable lock slot	Yes
Cable lock slot type	Kensington

Windows operating systems supported	Yes
Mac operating systems supported	MacOS

Master (outer) case height	302 mm
Master (outer) case width	258 mm
Master (outer) case length	808 mm
Master (outer) case gross weight	8870 g

Battery capacity	0.675 Wh

Heat dissipation	64 BTU/h
Operating relative humidity (H-H)	10 - 95 %
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C

Power source type	AC
AC input voltage	100 - 240 V
Current	4.74 A
DC input voltage	19 V
Battery technology	Lithium
Battery capacity	220 mAh
Number of batteries supported	1
Power plug type	Type C

Interface module dimensions (W x D x H)	246.2 x 171.3 x 56.1 mm
Interface module weight	1000 g
Width	719 mm
Depth	101 mm
Height	91.4 mm
Weight	4030 g
Package width	252 mm
Package depth	802 mm
Package height	289 mm
Package weight	8869 g

Cables included	AC,DC,HDMI,USB Type-A to USB Type-C
Power cable length	1.5 m
HDMI cable length	2 m
AC adapter included	Yes
Mounting kit	Yes
Quick start guide	Yes
Remote control included	Yes
Camera included	Yes
Batteries included	Yes
Packaging content	{loc-value}
