Produktbeskrivning
The professional Pro Series A/V line from Multibrackets was designed with the installer in mind. Modular, easy to configure, quick to install, and simple to maintain. Working closely with installers Multibrackets created a range with close to unlimited flexibility. This model the M Wallmount Pro MBW2UHD Micro Adjustable Black is no exception. The product provides the versatility and flexibility demanded by installers. Based upon the Pro Series strong and ultra-flexible aluminum rail it is completely modular and has built in cable management throughout the entire solution to quicken installation and creating an esthetic result worth the public eye.
With its modular construction installers have vast possibilities to change, create, update and reconfigure its design if ideas change over time, then Pro Series can follow.
With the built in fine tune adjustments each of the M Wallmount Pro MBW2UHD Micro Adjustable Black can be adjusted individually to match "its neighboring screens". With its built in simple to reach knobs, the screens can be adjusted in depth, side and height. What before could take hours for an installer to measure and re install, is now fixed in a matter of minutes. Truly an installers dream come true.
The Micro adjustable wallmounts also creates easy-access to a display to quick and safe serviceability for sensitive screens with mm precision. This is often one of the major functions needed when building a video wall mounting solution or when integrating a single screen into the wall.
Providing a clean Nordic look each part and detail serves its purpose. The result is a sleek Nordic solution emphasizing quality and function. Used in a variety of environments this ceiling mount is truly versatile and is made of the highest quality materials.
The Pro Series possibilities to extend aluminum rail change brackets and add details by individual choice is vast so that one can tailor each mount to its location and function. The Pro Series includes hardware so that a basic installation should not be a hassle.
Multibrackets Pro Series Public Wallmounts is ideal for any large screen digital signage wallmount application such as videowalls, menuboards and more.
Teknisk specifikation
Allmänt
| Bredd | 116.2 cm |
|---|
| Djup | 13 cm |
|---|
| Höjd | 15.8 cm |
|---|
| Justerbart djup | 0-1.5 cm |
|---|
| Vikt | 15 kg |
|---|
| Material | Plast, aluminium, stål |
|---|
| Färg | Svart |
|---|
| Förpackningens innehåll | Sats med fästelement |
|---|
AV-komponenter
| Typ | Monteringssats |
|---|
| Monteringskomponenter | Räls, 8 förlängningsskenor, 2 mikrojusterbara armar (40 cm), 2 ändkåpor för stång, 3 mindre väggplåtar |
|---|
| Rekommenderad användning | 2 LCD-bildskärmar |
|---|
| Placering/Montering | Väggmonterbar |
|---|
| VESA-infästningsgränssnitt | 100 x 100 mm, 200 x 200 mm, 400 x 400 mm, 600 x 400 mm, 300 x 300 mm, från 100 x 100 mm, 400 x 420 mm |
|---|
| Kabelhantering | Inbyggd kabelhantering |
|---|
| Rekommenderad TV-storlek | 65"-75" |
|---|
| Lutning | -4° to 4° |
|---|
| Justeringar | Lutning, djup |
|---|
| Maxlast | 70 kg |
|---|
| Ytskikt | Pulverlackerad |
|---|
| Detaljerad information | Stående orientering, liggande orientering |
|---|
Tillverkarens garanti
| Service och support | Begränsad garanti - 5 år |
|---|
