The NETGEAR AV Line series was designed with input from AV Professionals. The result is a line of switches built from the ground up to support 1Gb audio and video over IP with customized hardware and software.
NETGEAR IGMP Plus enables instant multicast functionality for most AV over IP installations.
Unique interface designed for the AV professional with color-coded, port-based profiles.
Quickly assign profiles to ports for Dante, AES67, and AVB audio configurations.
Special profiles for NVX, SVSI, Q-SYS and Dante video profiles can be easily assigned to ports as needed.
Allmänt
| Typ av enhet | Switch - 24 portar - L3 - Administrerad |
|---|
| Modell | Sida till sida luftflöde rackmonterbar 1U |
|---|
| Undertyp | Gigabit Ethernet |
|---|
| Portar | 24 x 10/100/1000 (PoE+) + 2 x 10/100/1000 + 4 x 1000Base-X SFP |
|---|
| PoE (Power Over Ethernet) | PoE+ |
|---|
| PoE-budget | 300 W |
|---|
| Prestanda | Växlingskapacitet: 60 Gbps
Brandväggsgenomströmning (64 bitars paketstorlek): 44.64 Mpps
1 Gbps fiberlatens (64-bytepaket): 1.164 µs
1 Gbps fiberlatens (512-bytepaket): 1.129 µs
1 Gbps fiberlatens (1024-bytepaket): 1.124 µs
1 Gbps fiberlatens (1518-bytepaket): 1.146 µs
1 Gbps kopparlatens (64-bytepaket): 2.146 µs
1 Gbps kopparlatens (512-bytepaket): 2.148 µs
1 Gbps kopparlatens (1024-bytepaket): 2.14 µs
1 Gbps kopparlatens (1518-bytepaket): 2.15 µs |
|---|
| Kapacitet | ARP-poster: 4000
NDP-poster: 4000
Paketets bufferstorlek: 16 MB
VLAN-stöd: 4093
IGMP multicastgrupper: 4000
QoS-maskinvarukörer: 8
IPv4-routes (statisk): 64
IPv6-routes (statisk): 64
RIP-programrouting skalning (IPv4): 32
IPv4-grupper (Multicast): 512
IPv6-grupper (Multicast): 128 |
|---|
| MAC Address Table Size | 16K poster |
|---|
| Jumbo Frame-support | 12KB |
|---|
| Nätverksprotokoll | RIP-1, RIP-2, IGMPv2, IGMP, PIM-SM, PIM-DM, IGMPv3, PIM-SSM, statisk IPv4-routing, statisk IPv6-routing, PBR (policy-based routing), MLDv2, MLD, PIM-SMv6, PIM-DMv6, MSTP, RSTP, STP |
|---|
| Protokoll för administration på distans | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH, SSH-2, CLI, SCP, SFTP, ICMP, DHCP, TACACS+, RADIUS |
|---|
| Krypteringsalgoritm | AES, TLS 1.0, SSL 3.0, TLS 1.2 |
|---|
| Verifieringsmetod | Secure Shell (SSH), RADIUS, TACACS+ |
|---|
| Funktioner | Flödeskontroll, automatisk avkänning per enhet, BOOTP-stöd, IGMP snooping, portspegling, Stöd för DiffServ, lagra och vidarebefordra, MAC-adressfiltrering, Broadcast Storm Control, fullt duplexläge, Multicast Storm Control, Unicast Storm Control, SNTP-support, Weighted Random Early Detection (WRED), sFlow, DHCP-snooping, Quality of Service (QoS), DHCP-server, MLD-snooping, Dynamic ARP Inspection (DAI), STP Root Guard, Uni-Directional Link Detection (UDLD), LACP-support, LLDP-support, DHCP-relä, Port Security, Remote Switch Port Analyzer (RSPAN), Energy Efficient Ethernet, Multicast VLAN Registration (MVR), dubbel bild med fast programvara, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), Class of Service (CoS), Strict Priority (SP), Generic Attribute Registration Protocol (GARP), Generic VLAN Registration Protocol (GVRP), IGMP-proxy, 802.1x-autentisering, Precision Time Protocol (PTP), stöd för DiffServ Code Point (DSCP), kabeltest, MLD-proxy, IP-källskydd, GARP Multicast Registration Protocol (GMRP), Source-Specific Multicast (SSM), DNS-klient, Voice VLAN, LLDP-MED, RA-skydd, STP BPDU Guard, STP-loopskydd, Denial of Service (DoS) protection, Protocol Independent Multicast (PIM), Audio Video Bridging (AVB), MAC Access Bypass (MAB), Link Aggregation Group (LAG), protokollidentifierare med multipla taggar (TPID), IPTV-support, hanterad åtkomstkontroll och administrationslista (MACAL), Discovery-protokoll av industristandard (ISDP), Rapid PVST+ (RPVST+), Multiple Registration Protocol (MRP), STP BPDU Filtering, STP BPDU Flooding, MGMD Snooping, Any Source Multicast (ASM) |
|---|
| Standarder som följs | IEEE 802.3, IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3ac, IEEE 802.1s, IEEE 802.1v, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
|---|
| Processor | X ARM: 1.8 GHz |
|---|
| RAM | 2 GB |
|---|
| Flash-minne | 256 MB |
|---|
| Statusindikatorer | Portstatus, strömförsörjning, fläkt, PoE max |
|---|
