Produktbeskrivning
NETGEAR brings even larger PoE budgets on unmanaged switches with Ultra60 PoE++ technology with the 16-port unmanaged switch, ideal for powerful PoE+/PoE++ installations with a compact size, plug-and-play installation, and reliable performance. Standardized to IEEEE 802.3bt, the Ultra60 PoE++ switch can deliver up to 60W of power per port, allowing the connections of higher power required devices, such as high-performance 802.11AX wireless access points, PTZ and 4K IP surveillance cameras, PoE lighting, PoE-powered audio speakers, as well as other high-powered devices. The GS516UP has a PoE mode used to enable pre-802.bt compatibility for pre-bt devices that were created before 802.3bt Standard was ratified.
Egenskaper
● Simple setup with no software or configuration needed
● Per port LEDs for port activity and speed
● Energy-efficient technology for power savings
● Auto-negotiation for automatic connection at the highest common speed between switch and an end device
● Auto-MDI/MDIX eliminates the need for crossover cables
● Small, sturdy desktop metal case and quiet operation
● Ideal for small and medium offices
● Non-blocking switching architecture for maximum throughput at wire speed
● Standards-based technology ensures interoperability with any standards-based devices in the existing network
● 802.3at Power Over Ethernet (PoE+) for IP cameras, VoIP/Internet-based phones, and wireless access points
● Unique PoE technology automatically balances the PoE power based on the device needs independent of PoE class detected
Teknisk specifikation
Allmänt
| Typ av enhet | Switch - 16 portar - ohanterad |
|---|
| Modell | Skrivbordsmodell, rackmonterbar |
|---|
| Undertyp | Gigabit Ethernet |
|---|
| Portar | 8 x 10/100/1000 (PoE+) + 8 x 10/100/1000 (PoE++) |
|---|
| PoE (Power Over Ethernet) | PoE++ |
|---|
| PoE-budget | 380 W |
|---|
| Funktioner | Auto-negotiation, auto-uplink (auto MDI/MDI-X), metallhölje |
|---|
| Standarder som följs | IEEE 802.3at, IEEE 802.3bt |
|---|
| Statusindikatorer | Strömförsörjning, PoE, länk/akvititet, fläkt |
|---|
Expansion/Anslutning
| Gränssnitt | 16 x 10/100/1000 Base-T RJ-45 8 portar (PoE++)/8 portar (PoE+) - 60 W |
|---|
Diverse
| Lokalisering | Stillahavsasien, Storbritannien, Europa |
|---|
Dimensioner och vikt
| Bredd | 33 cm |
|---|
| Djup | 20.7 cm |
|---|
| Höjd | 4.3 cm |
|---|
| Vikt | 2.6 kg |
|---|
