Produktbeskrivning
This GBIC is built to insert into any one of the two built-in 10 GE SFP+ interfaces of GSM7328Sv2 and GSM7352Sv2, and into the 10GE SFP+ interface of AX743 adapter module for GSM73xxS/GSM73xxSv2. Once inserted (hot-swappable), the AXM761 10GBASE-LR SFP+ (LC connector) drives 10 Gigabit Ethernet up to 10 km distances with 9/125µm SMF single mode fiber cables, or up to 33 m distances with 62.5/125µm OM1 multimode fiber cables.
Egenskaper
● Adds 10Gigabit Ethernet "long-reach" LC fiber connectivity to the standard SFP+ interfaces
● Fits into the two built-in 10GE SFP+ interfaces of GSM72xxPS / GSM73xxS
● Fits into the 10GE SFP+ interface of the SFP+ Adapter module AX743
● Fits into standard 10 Gigabit SFP+ interfaces
● LC connector
● Drives 10 Gigabit Ethernet up to 10 km distances with 9/125 µm SMF single mode fiber cables
● Drives 10 Gigabit Ethernet up to 300 m distances with 50/125 µm laser-optimized OM3 multimode fiber cables
● Drives 10 Gigabit Ethernet up to 33m distances with 62.5/125 µm OM1 multimode fiber cables
● Provides hot-swappable installation or removal
● 10GBaseLR fiber technology is the same for XFP and SFP+: one Switch equipped with XFP 10GBase-LR LC connectivity can uplink to another Switch equipped with SFP+ 10GBase-LR LC connectivity using the same fiber
Teknisk specifikation
Allmänt
| Typ av enhet | SFP+ sändar/mottagarmodul |
|---|
| Formfaktor | Insticksmodul |
|---|
Nätverksfunktioner
| Anslutningsteknik | Kabelansluten |
|---|
| Typ av kablage | 10GBase-LR |
|---|
| Datalänkprotokoll | 10GbE |
|---|
| Max överföringsavstånd | 10 km |
|---|
Expansion/Anslutning
| Gränssnitt | 1 x Ethernet 10GBase-LR |
|---|
| Kompatibla kortplatser | 1 x SFP+ |
|---|
Kompatibilitetsinformation
| Designat för | NETGEAR GSM7228PS, GSM7252PS, GSM7328S, GSM7352S, M4300-28G-PoE+ |
|---|
