Produktbeskrivning

The FM415 Bass is designed for fast, straightforward 2D scanning applications. With its intelligent programming, it can be set to read optimally from both close and long distances. Additionally, its power efficiency reduces power consumption and prolongs service life. This stationary scanner is ideal for smoothly transitioning from 1D to 2D scanning without increasing the budget.

Snappy, even in less than perfect conditions
A combination of the IR sensor and the light sensor helps keep workers moving, even in low light conditions. Its strong, white light ensures barcodes are always well lit.

Handsfree or manual scanning
Companies looking for automatic scanning to relieve manual labor can set up the FM415 Bass for hands free scanning. Alternatively, a manual trigger button can be used if preferred.

Intelligent programming
The sensors of the FM415 Bass automatically adjust the brightness of supplementary lighting based on the light that reflects off the barcode. This also makes it an optimal solution for scanning from mobile phone screens. Depending on the application, the scanner can be set to optimally read from close and long distance.

Reliable outdoor use
With an IP rating of 54, this fixed mount scanner can be placed in a housing and used outdoors without worrying about dust or moisture.



Viktiga egenskaper

Newland FM415 Bass. Type: Barcode module bar code reader, Scanner type: 1D/2D, Sensor type: CMOS. Connectivity technology: Wired, Standard interfaces: RS-232, USB. Product colour: Black, International Protection (IP) code: IP54, Protection features: Drop resistant. Power source type: USB, Power consumption: 228 mA. Weight: 64.6 g, Width: 49 mm, Depth: 69 mm



Teknisk specifikation

Type	Barcode module bar code reader
Scanner type	1D/2D
2D (matrix & stacked) barcodes supported	Aztec Code,Data Matrix,MaxiCode,Micro QR Code,MicroPDF417,PDF417
Sensor type	CMOS
Linear (1D) barcodes supported	AIM-128,Codabar,Code 11,Code 128,Code 39,Code 93,EAN 128,EAN-13,EAN-8,GS1 DataBar,GS1 DataBar Expanded,GS1 Databar Limited,GS1 Databar RSS14,GS1-128 (UCC/EAN-128),ISBN,ISSN,ITF-14,ITF-6,Industrial 25,Interleaved 2 of 5,MSI-Plessey,Matrix 2 of 5,Plessey,St
Optical sensor resolution (W x H)	640 x 480 pixels
Horizontal field of view	42 °
Vertical field of view	31.5 °
Pitch reading angle	-60 - 60 °
Yaw reading angle	-60 - 60 °

Connectivity technology	Wired
Standard interfaces	RS-232,USB
USB 2.0 ports quantity	1

Product colour	Black
International Protection (IP) code	IP54
Protection features	Drop resistant
Buzzer	Yes
Print contrast	25 %

Power source type	USB
Power consumption	228 mA

Width	49 mm
Depth	69 mm
Height	20 mm
Weight	64.6 g

Storage temperature (T-T)	-40 - 70 °C
Drop resistance	1.5 m
Operating relative humidity (H-H)	5 - 95 %
Operating temperature (T-T)	-20 - 60 °C

Compliance certificates	CE,Federal Communications Commission (FCC)
